Specifications
Structure Length Standard: GB / T12221-2005
Flange Standard: GB / T9113
Pressure temperature rating: GB / T12224-2005
Test te
Electric control valve Product Model: 600X
Product Caliber: DN20-600
Product pressure: 1.0-2.5Mpa
Material: cast iron, cast steel, stainless steel, etc.
Product Description:
Manufacturing standards: Chinese GB, Department of Mechanical JB, chemical industry standards HG, American standard API, ANSI, German standard DIN, Japanese JIS, JPI, British standard BS production. Body material: copper, cast iron, cast steel, carbon steel, WCB, WC6, WC9,20 #, 25 #, forged steel, A105, F11, F22, stainless steel, 304,304L, 316,316L, chromium-molybdenum steel, cold steel, titanium steel. Working pressure 1.0Mpa-50.0Mpa. Working temperature: -196 ºC -650 ºC. Connection: internal thread, external thread, flange, welding, butt welding, socket welding, card sets, clamps. Driving modes: manual, pneumatic, hydraulic, electric. The valve Holding (Group) Co., Ltd. has the world's best engineers, production equipment and technology, the ability to follow national standards and a variety of industry-standard manufacturing high quality valves.
Product details:
Products:
600X electric control valve is a solenoid valve for the wizard hydraulic valve operated valves. Commonly used in the installed drainage system piping and industrial automatic control, quickly and accurately control the reaction, opening and closing the electric control valve to achieve open and closed piping system remote control, remote operation of electrical signal remote control. Can replace the valve or butterfly valve to open and close a large electric devices, small size, light weight, simple maintenance, easy to use, safe and reliable.
Applications:
600X electric control valves and industrial systems applied to the drainage pipes, all kinds of pipes, water systems.
Structural features:
Valve closing speed adjustable, smooth closed without generating pressure fluctuations. 600X electric control valve, small size, light weight, simple maintenance, easy to use, safe and reliable. Optional AC solenoid valve 220V, or DC 24V, can be a variety of occasions, normally open or normally closed type can be based.
Standard specification:
Design and manufacturing standards:
Structure Length Standard: GB / T12221-2005
Flange Standard: GB / T9113
Pressure temperature rating: GB / T12224-2005
Test test: GB / T13927-2008
Technical Parameters
Pressure rating:1.0Mpa-2.5Mpa | Design and manufacture:GB/T12239-1989 |
Medium:Water | Flange connection:GB/T17241.6-2008 |
Applicable temperature:≤80ºC | structure length:GB/T12221-2005 |
Aperture:DN40-DN800 | Pressure test:JB/T9092-1999 |
