Product Features:
1/. Normal close, brass body
2/. For high pressure application, Import PTFE seal material
3/. Piston pilot solenoid valve with high working pressure and temperature
Model | SLG5404-15 | SLG5404-20 | SLG5404-25 |
Medium | Water, Gas, Oil |
Acting type | Pilot type |
Orifice(mm) | 12 | 20 | 25 |
CV Valve | 2 | 5 | 10 |
Port Size | 1/2'' | 3/4'' | 1'' |
Working Pressure(Bar) | Gas:1-50, Liquid:1-25 | Gas:1-40, Liquid: 1-25 | Gas:1-40,Liquid: 1-25 |
Max.working pressure(Bar) | 75 | 60 | 60 |
Working temperature range | -10ºCºC-150 |
Power Consumption | AC5.5VA,DC9W |
Material of valve body | Brass |
Seal Material | PTFE |
