Specification
Model 2W-160-10 2W-160-15 2W-200-20 2W-250-25 2W-350-35 2W-400-40 2W-500-50
Working Medium Air, Water, Oil, Gas
Motion Pattern Direct Drive Type
Type Normal Close Type
Aperture of Flow Rate mm 16 20 25 35 40 50
CV Value 4.8 7.6 12 24 29 48
Joint Pipe Bore 3/8" 1/2" 3/4" 1"11/4" 11/2" 2"
Operation Fluid Viscosity 20CSTBelow
Working pressure Air: 0~1.0Mpa\ Water: 0~0.7Mpa\ Oil: 0~0.7Mpa
Max. Pressure Resistance 1.0Mpa
Operating Temperature -5~80 degree
Voltage Range: 10%
Material of Body Brass
Material of Oil Seal NBR or VITON
Model | 2W160-10 | 2W160-15 | 2W200-20 | 2W250-25 | 2W350-35 | 2W400-40 | 2W500-50 |
Working Medium | Air, Water, Oil, Gas |
Motion Pattern | Direct Drive Type |
Type | Normal Close Type |
Aperture of Flow Rate mm | 16 | 20 | 25 | 35 | 40 | 50 |
CV Value | 4.8 | 7.6 | 12 | 24 | 29 | 48 |
Joint Pipe Bore | 3/8″ | 1/2″ | 3/4″ | 1″ | 1 1 /4″ | 1 1 /2″ | 2″ |
Operation Fluid Viscosity | 20CSTBelow |
Working -pressure | Air: 0~1.0Mpa. Water: 0~0.1Mpa. Oil: 0~0.1Mpa |
Max. Pressure Resistance | 1.0Mpa |
Operating Temperature | -5~80 degree |
Voltage Range | ±10% |
Material of Body | Brass |
Material of Oil Seal | NBR or VITON |
Yuyao DingFeng HyDraulic Co., Ltd. As a professional manufature and exporter, Yuyao Dingfeng Hydraulic Co., Ltd was established in 2007, located in the south bank of Hangzhou Gulf Bridge which is the longest bridge in the world, near the NingboBeilun Port, have convenient transportation.
We can produce all kinds of EATON and SAE standard fittings and adapters.
We specialized in exploiting, manufacturing and selling fluid flow systerm. Dingfeng products includes: All kinds of hydraulic hose fittings, adapters, hydraulic hose, high pressure hose assemblies and other metal parts, as well as the agent for related fluid joint products. We also provide OEM service.
These products are mainly used in aerospace, automotive, shipbuilding, medicine, chemicals, petroleum and other areas.
We are dedicating to manufacture good quality products and provide high level service to win the market and our customers' trust. Our products are very popular in American, Europe, Japan, Australia and so on. Welcome new and old customers, from home and abroad, to invest and cooperate with us.
With the belief of "keep improvement, pursue higher", we strive to create a splendent future with you by our excellent products and satisfy service!
