2 Piece Stainless Steel Flanged Ball Valve with Mounting Pad

2 Piece Stainless Steel Flanged Ball Valve with Mounting Pad
Price: US $ 20-350/Set
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union



We will give you a reply within 24 hours after receiving your inquiry



2 pcs Body Flanged Ball Valve



ISO5211 Direct mounting pad for optional

1.Fire safe is avaliable

2.Full Bore

3.Size : 1/2"~4" (DN15~DN100)

4.Working Pressure :150Lb~300Lb /PN16~40

5.Working Temperature :-20°C~250°C

6.Material :WCB,CF8,CF8M etc



Feature

 Double O-Rings third stem sealing design

 Blow-out proof stem

 Built-in ISO5211 direct mounting pad

 Invisible gland  design

 Pre-load 2 Belleville washer to self-adjust packing

 Double Stem sealing to comply with TA-LUFT requirements

 Anti-static devices for ball-stem body

 Fire safe design and Construction


Specification
Design: ASME B16.34 ,API608
Face to face: ASME B16.10
End Flange: ASME B16.5
Wall thickness: ASME B16.34
Inspection &Testing: API598



Prod Model: Q41F-150P
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 1/2" ~4"
Medium: Water,Oil ,Gas etc
Connection Form: Flange
Channel: Straight Through Type
Structure: Floating Ball Valve
Type: Floating Ball Valve
Application: Household Usage
Material: Stainless Steel ,Carbon Steel
Driving Mode: Manual ,Pneumatic ,Electric,Hydraulic etc
Nominal Pressure: ANSI 150~300lb
Function: Cut off
Zhejiang Ouming Fluid Casting Industry Co., Ltd was founded in 1983, the head office is located in valves and pumps capital-Wenzhou. It has more than 150 staffs and covers an area of 15000 square meters

We professionally manufacture valves, pipe fittings, castings and other fluid system equipments, including ball valves, gate valves, globe valves, check valves, diaphragm valves, Plug valves, sanitary butterfly valve, elbows, tees, union and other pipe fittings. All Products Strictly meet the GB, ANSI, JIS, DIN, BS, ISO, etc. They are widely used in Petrochemicals, Chemical, LNG& Cryogenics, Pulp & paper, Water and Wastewater, Mining, Refining, Marine, Electric power etc. Besides, they have been exported to Europe, North America, Middle East, Southeast Asia regions, etc.

We are a modern manufacturer in valve, pipe fitting and casting with the silica sol investment casting process. We own modern high-precision casting equipment and advanced machining equipment and testing equipment. Eg, CNC machining centers, CNC lathes, Spectrometer, Ultrasonic Tester, Magnetic Particle Testing, etc. These equipments ensure the product's good quality and we are approved by ISO9001, CE and TS, etc.

We commit to provide supreme quality of products and 100% customer satisfaction service, based on the principle of honesty and trustworthiness, we focus on controlling quality, improving management and contentiously developing new market and enlarging our product range. Welcome to contact and join us for the promising business.
