Applicable Standard:
Design Standard: API 600, BS1414, DIN3352
Face to Face: ASME B16.10, EN 558, DIN3202
End Flange: ASME B16.5, ASME B16.47, DIN2533
Buttwelding Ends: ASME B16.25, DIN3239
Inspection and Test: API 598, DIN3230
Design Features:
Full port design
OS&Y, outside and screw
Bolted bonnet, back seal structure
Flexible wedge, fully guided
Choice of Solid or split wedge
Extended stem design for low temperature
Flanged or butt-welding ends
MAIN PARTS & MATERIALS:
Part Names | Part Materials |
Body | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
Bonnet | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
Disc/Ball/Wedge | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
Stem | F6a | F304 | F6a | F304 | F316 | F304L | F316L | C83600/C95800 |
Seat/Seat Ring | 13%Cr | SS304 | 13%Cr | SS304 | SS316 | SS304L | SS316L | C83600/C95800 |
Packing | Graphite/PTFE |
Gasket | SS304+Graphite/SS304+Graphite |
Bolts/Nuts | B7/2H | L7/4 | B16/4 | B8/8 | B8M/8M | B8/8 | B8M/8M | B8M/8M |
Suitable Medium | W.O.G etc. | HNO3, CH3OOH etc. | Sea Water etc. |
Suitable Temperature | -29~425 °C | -46~340 °C | -46~340 °C | -196~427 °C | -196~427 °C | -196~427 °C | -196~427 °C | -29~220 °C |
Bellow Seal Gate Valve:
Pressure: Class 150--Class 600
Size: 1/2"--14"
Flat Gate Valve:
Pressure: Class 150--Class 900
Size: 2"--40"
Pressure Seal Gate Valve:
Pressure: Class600--Class 2500
Size : 2"--24"
