2L Series High Temperature Solenoid Valve
Price: |
US $ 5.60/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
5/Piece |
Pay Type: |
L/C,T/T,Western Union |
It is a kind of pilot steam 2/2 way valve. It can work under 180 ºC, mainly used for controlling the steams, that's why called the steam solenoid valve. The thread size is from 3/8" to 2". The working pressure for this solenoid valve is high, which can reach 1.5 MPa. The orifice sizes for this valve is also bigger than normal valve for same thread sizes to make the flow rate bigger. With its steady performance, this type of solenoid valve is widely used in the steam control systems in different industries.
Characteristic:
Type: Nomal close
Joint size: 3/8" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
Flow Ratea: 17mm 22mm 30mm 50mm
Pressure: 1~1.5Mpa
Temperature: -5~185 centigrade
Material: Brass Bronze
Seal Material: PTFE
Model |
US-10 |
US-15 |
US-20 |
US-25 |
US-35 |
US-40 |
US-50 |
Working Medium |
Air, Water, Steam |
Motion Pattem |
Guid Type |
Type |
Normal Close Type |
Aperture of Flow Ratea MM |
17 |
22 |
30 |
50 |
Cv Value |
4.8 |
12 |
20 |
48 |
Joint Pipe Bore |
3/8" |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
Operation Fluid Viscosity |
20 CST (Below) |
Working-pressure |
1~15kgf/cm2 |
Max. Pressure Resistance |
22.5kgf/cm2 |
Operating Temperature Range |
-5~180 |
Voltage Range |
±10% |
Material of Body |
Brass |
Material of Oil Seal |
PTFE |
Prod Model: |
2L |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Port Size: |
3/8"-2" |
Seal Material: |
Telfon |
Type: |
Direct Acting |
Connection Form: |
Thread |
Valve Structure: |
Direct-Acting Piston Structure |
Power Supply: |
AC Solenoid Valve |
Application: |
Water Industrial Usage |
