FEATURES
1. Compact volume, large flow, widely use
2. Protection class: IP65, dust proof and water proof, can be used for outdoors
3. DIN connector and wire leads are available
4. Insulation grade: H class, good resistance to high temperature;
5. NBR, VITON, EPDM, SILICONE seals are available
6. Normally closed and normally open
SPECIFICATIONS
Specification for 2N Series Normally Closed Solenoid Valve
| Model | Thread Size (G) | Orifice (mm) | CV | Working Pressure (Bar) | Seals | Voltage |
| AC | DC |
| Brass body | Stainless steel | air, gas | water | ≤20cst oil | air, gas | water | ≤20cst oil |
| 2N030-06 | 2N030-06B | 1/8" | 3 | 0.3 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 | 0-5 | NBR seals ≤80ºC; Viton seals ≤150ºC; EPDM seals ≤120ºC Silicone seals ≤100ºC | 220VAC 110VAC 24VDC 12VDC make Other voltage as requested |
| 2N030-08 | 2N030-08B | 1/4" | 3 | 0.3 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 | 0-5 |
| 2N040-08 | 2N040-08B | 1/4" | 4 | 0.58 | 0-5 | 0-5 | 0-4 | 0-4 | 0-4 | 0-3 |
| 2N050-08 | 2N050-08B | 1/4" | 5 | 0.65 | 0-4 | 0-4 | 0-3 | 0-3 | 0-3 | 0-2 |
| 2N060-08 | 2N060-08B | 1/4" | 6 | 0.8 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N150-10 | 2N150-10B | 3/8" | 15 | 4.6 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N150-15 | 2N150-15B | 1/2" | 15 | 4.6 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N200-20 | 2N200-20B | 3/4" | 20 | 8.5 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N250-25 | 2N250-25B | 1" | 25 | 12 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N320-35 | 2N320-35B | 1 1/4" | 32 | 24 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N400-40 | 2N400-40B | 1 1/2" | 40 | 29 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N500-50 | 2N500-50B | 2" | 50 | 48 | 0-7 | 0-7 | 0-7 | 0-5 | 0-5 | 0-5 |
| 2N250-25F | 2N250-25FB | 4 holes flange | 25 | 12 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N320-35F | 2N320-35FB | 32 | 24 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N400-40F | 2N400-40FB | 40 | 29 | 0-10 | 0-10 | 0-10 | 0-7 | 0-7 | 0-7 |
| 2N500-50F | 2N500-50FB | 50 | 48 | 0-7 | 0-7 | 0-7 | 0-5 | 0-5 | 0-5 |
Specification for 2N Series Normally Open Solenoid Valve
| Model | Thread Size (G) | Orifice (mm) | CV | Working Pressure (Bar) | Seals | Voltage |
| AC | DC |
| Brass body | Stainless steel | air, gas | water | ≤20cst oil | air, gas | water | ≤20cst oil |
| 2N030-06H | 2N030-06BH | 1/8" | 3 | 0.3 | 0-7 | 0-7 | 0-6 | 0-6 | 0-6 | 0-4 | NBR seals ≤80 ºC Viton seals ≤150ºC EPDM seals ≤120ºC Silicone seals ≤100ºC | 220VAC 110VAC 24VDC 12VDC make Other voltage as requested |
| 2N030-08H | 2N030-08BH | 1/4" | 3 | 0.3 | 0-7 | 0-7 | 0-6 | 0-6 | 0-6 | 0-4 |
| 2N040-08H | 2N040-08BH | 1/4" | 4 | 0.58 | 0-4 | 0-4 | 0-3 | 0-3 | 0-3 | 0-2 |
| 2N050-08H | 2N050-08BH | 1/4" | 5 | 0.65 | 0-3 | 0-3 | 0-2 | 0-2 | 0-2 | 0-1 |
| 2N060-08H | 2N060-08BH | 1/4" | 6 | 0.8 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N150-10H | 2N150-10BH | 3/8" | 15 | 4.6 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N150-15H | 2N150-15BH | 1/2" | 15 | 4.6 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N200-20H | 2N200-20BH | 3/4" | 20 | 8.5 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N250-25H | 2N250-25BH | 1" | 25 | 12 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N320-35H | 2N320-35BH | 1 1/4" | 32 | 24 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N400-40H | 2N400-40BH | 1 1/2" | 40 | 29 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N500-50H | 2N500-50BH | 2" | 50 | 48 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N250-25FH | 2N250-25FBH | 4 holes flange |
| 12 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N320-35FH | 2N320-35FBH | 32 | 24 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N400-40FH | 2N400-40FBH | 40 | 29 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
| 2N500-50FH | 2N500-50FBH | 50 | 48 | 0-5 | 0-5 | 0-3 | 0-3 | 0-3 | 0-3 |
ADVANTAGE
1) Raw Material conforms to China industry standard, bought from famous factory.
2) Insulation grade: H class, good resistance to high temperature;
3) Machined by CNC to make sure the tolerance as the drawing
4) 100% leakage testing under low pressure and high pressure.
5) All kinds of valve and seals material to meet custom requirement.
6) 1 year quality assurance after shipment.
7) After sales technique support
WHY CHOOSE US?
1) We offer one stop solution. Over 5000 items for you to save efforts and costs.
2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.
3) We will reply you within 24 hours.
4) Whatever quantity you are requesting, we always offer you the best quality.
5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder
FAQ
Packing
Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available
Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.
Payment Terms
We accept T/T, L/C, Paypal, western union,etc.
Samples Policy
For regular fittings below 20 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.
Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.
============================================================
We have thousands of solenoid valve in the stock. If you do not know how to order our valve, please tell us some necessary information, we will recommend you the most economical solenoid valve.
1. valve material
2. working pressure
3. temperature range
4 working environment
5. quantity
You can choose as below
Body Material: Plastic, brass, SS304, SS306, Steel.
Seal Material: NBR, VITON, PTFE, EPDM, SILICONE
Voltage: 12VDC, 24VDC, 24VAC, 220VAC, 280VAC
Size: M5-2", Flange connection
