2PC/3PC Flanged/Welded Stainless Steel Ball Valve

2PC/3PC Flanged/Welded Stainless Steel Ball Valve
Price: US $ 158/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T
Metal hard seal ball valve is the latest development of high performance ball valve, to solve the sticky tape to prevent the sealing surface and high-temperature jamming phenomenon. The use of disc spring loaded seat seal structure, can effectively compensate for thermal expansion of the inner parts, easy to open and close at high temperatures, and sealed with a two-way function.

For users of different work conditions and requirements, you can use a variety of advanced hardening of the ball and seat technology, including supersonic spraying, nickel-based spray, special surface hardening, carbide spray and so on. In order to ensure that the valves in a variety of temperature and pressure of a reliable seal, ball and seat surface hardness can reach HRC60 or more generally, up to HRC74 or more.

Sealing surface material also has good abrasion resistance, erosion and other properties. Can be applied to most harsh working conditions.
For Class150 ~ 1500, PN1.6 ~ 16.0MPa, working temperature -29 ~ 425ºC (carbon steel) or -40 ~ 500 ºC (stainless steel) of various piping, cut off or connected to the pipeline for the media. Use of different materials, can be applied to water, steam, oil, nitric acid, acetic acid, urea, ash, and other oxidizing medium.
Prod Model: Q41F
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Channel: Straight Through Type
Structure: Floating Ball Valve
Type: Floating Ball Valve
Material: Stainless Steel
Application: Household Usage
Connection Form: Welding/Flange/Thread
Wenzhou Pioneer Valve Co., Ltd. is located in China Valve City----Longwan District, with a distance of 5km to Wenzhou Airport, specialized in doing with ball valves for more than 20 years. Have Wafer Type Ball Valve enterprise standard, is a member of China valve industry association, China vacuum equipment industry association member and China detergent technical equipment professional committee member. Pioneer is a technology innovation-based valve manufacturer, "OULIFA" is a registered trademark of the pressure valve, and "PIONEER" is a registered trademark of the vacuum valve.

Since 1993 we are committed to product R&D, absorption, innovation, precision manufacturing and 100% quality testing. We accumulated technical experience and developed our own ERP business management software, to achieve enterprise-wide process information management and also passed the ISO9001: 2008 quality management system certificate, PED97/23/EC CE certificate and the TS certificate (manufacture License of the special equipment, pressure piping components).

In production, we actively absorb advanced technology, use high-precision CNC machining equipment and testing equipment for production and testing to make our products quality more reliable. We have developed wafer ball valve, high platform ball valve, tank bottom ball valve, jacket ball valve, three-way ball valve, metal seal ball valve, V-type adjust valve, sanitary ball valve and a number of representative pressure valve products. And we have been granted many national patents, three products awarded the title of the China International Silver Valve Expo, part products have record to the "China Valve New Product Catalog". Our products widely used in of chemical, pharmaceutical, shipbuilding, paper making, printing and dyeing, painting, environmental protection, grease, biotechnology, fine chemicals, food and beverage, water treatment, urban construction and etc.

"PIONEER" developed vacuum valves since 2005 and joined the China Vacuum Society and the China Vacuum Equipment Industry Association in August 2010. We have completed developed various of vacuum valves, especially in "vacuum Ball valve, vacuum Butterfly valve, vacuum Charge valve, Electromagnetic vacuum valve, vacuum Baffle valve, vacuum Angle valve, vacuum Gate valve". The valves are driven approach: Manual, Pneumatic, Electromagnetic, Electric. Each product goes through rigorous test and helium mass spectrometer leak detector test. Used in the field of vacuum technology, like machinery, electronics, metallurgy, refrigeration, medicine, food, energy, environmental protection, scientific research, and etc.

"Quality as the pioneer, service as the backup force" is our business concept. With highly capacities of developing, design and manufacturing, we ensure to provide high quality products and also do OEM / ODM which meet your requirements as well. We sincerely hope to establish long-term partnership with old and new customers in the future.
