Feature:
1.Anti-static devices for ball-stem body
2.Fire safe design and Construction
3.Pressure Balance Hole in Ball Slot
4.Various Connection End Standard Available
5.ISO-5211 Mounting Pad for Actuator Available
| Size: | 1/2"- 4'' |
| Working Pressure : | 150Lb~300Lb /PN16~40 |
| Working Temperature : | -20°C~180°C |
| Material : | WCB,CF8,CF8M etc |
| Seat Material: | PTFE, RPTFE (15% Glass Fiber), RPTFE (25% Carbon Fiber), PPL etc. |
| Port : | Full Bore |
| Connection : | Flange |
| Operation : | Pneumatic |
| Suitable Medium: | Water, Oil, Air and Some Corrosive Liquid |
| Design: | ASME B16.34 ,API608 |
| Face to Face: | ASME B16.10 |
| End Flange: | ASME B16.5 |
| Wall thickness: | ASME B16.34 |
| Inspection &Testing: | API 598 |
