Direct Acting Poppet, Normally Closed — DN2.5mm
Direct acting normally closed solenoid poppet valves available either AC or DC operated in plastic body. High flow with stainless steel seat and soft magnetic alloy and EPDM disc for hot water applications. Field replaceable seat/orifice design for flexibility.
Technicial specifications:
Food grade fiaphragm, sealed component
[Technical Specifications ]
-- Media: Water, Air, Vacuum
--Function type: Normally Closed(N/C)
--Temperature: 0 ÷ 100ºC
--Mode of action: Direct acting type
--Body material: PP + Fiber glass, Brass
-- Sealing material: EPDM
--Protection class: IP65
United conversion:
Pressure: 1kg/cm2=1bar=0.1MPa=14.2233psi
1psi=0.069bar
We are China plastic solenoid valve manufacturer offer best plastic solenoid valve OEM, ODM, service
Model |
G NPT Connection |
Orifice Size |
Cv Value |
L |
H |
H1 |
Medium temperature |
Pressure |
Power |
inch |
mm |
mm |
mm |
mm |
bar |
RSO-SL |
1/4" |
2.5 |
0.21 |
41 |
62 |
52 |
0 & divide; 100& ordm; C
|
0 ~ 10; |
AC220/ 50-60HZ 4VA; DC24V, 8.5W Range: ± 10%, |
