Why choose us:
1. We have professional technicists to ensure advanced design.
2. We have professional and technical QC team to ensure 100% products checking.
3. We have own factory with competitive price and good quality.
4. Our products is accepted by all over the world.
5. We have own import and export right. Small order can be accepted.
6. High quality with competitive price, short delivery time.
7. Good quality material and advanced production equipment.
8. Efficient sales team and excellent customer service.
9. Our products have passed the CE and SGS Certificate.
|
Model |
HLF02
04D |
HLF02
08D |
HLF02
16D |
HLF02
24D |
HLF02
32D |
HLF02
04A |
HLF02
08A |
HLF02
16A |
HLF02
24A |
|
Output Torque |
4Nm |
8Nm |
16Nm |
24Nm |
32Nm |
4Nm |
8Nm |
16Nm |
24Nm |
|
Max Baffle Plate size |
1m |
2m |
4m |
6m |
6m |
1m |
2m |
4m |
6m |
|
Time for Rotating 90° |
35S |
30S |
80S |
125S |
140S |
35S |
30S |
80S |
125S |
|
Modulating Scope |
0~90° (In 5°Incerments) |
|
Operating Voltage |
24VAC/24VDC AC220V~230V 50/60Hz AC110V 50/60Hz |
|
Power Rating |
4W |
3.9W/4.8W |
4W |
2.5W |
4W/4.8W |
|
Control Input |
2/3( Flocating Points) |
0~10VDC 4~20mA |
|
Position Output |
|
0~10VDC 4~20mA |
|
Driving Shafts |
8~32Nm Cylinder shaft size: φ20mm; Square shaft size: 16x16mm |
|
4Nm Cylinder shaft size: φ16mm; Square shaft size: 12x12mm |
|
Housing |
ABS engineering plastic |
|
Ambient Temperature |
Operation:-20~+50°C Storage:-40~+80°C |
|
Relative Humidity |
0~90%RH |
|
Protection |
IP54 |
|
Noise Grade |
45Db (A) |
|
Net Weight |
8~32Nm: 1.1kg 4Nm :0.7kg |
|
Certificate |
CE, ISO9001 |
|
Usage life |
60,000 |
Wenzhou Heli Automatic Meter Co., Ltd. (HL) is a High-tech enterprises specialized in manufacturing electric actuator, pneumatic actuator, rotary air damper actuator, integrating scientific research, production, distribution and service.
Founded in 1999, covers an areas of 13118 square meters. HELI company consistently pays attention to product quality and all of HELI products have passed the CE certification, the test of Shanghai industrial Automatic Instrument Institute with every performance and index qualified, etc.
HELI will bring you much more convenience. By consistently keeping the management conception of taking market as guide, serving by quality and credit, and developing by technology and innovation. Our company guarantees to realize the goal of double-win with user's benefits as precondition. In the future, HELI people will actively take the challenge with excellent quality, scientific management and perfect service.
Sincerely welcome friends all over the world to come here for negotiation and cooperation.
