The hand lever valve used to control the admission of steam into, and emission of exhaust from, the cylinder of a steam engine.
Model
| 4H210-06
| 4H310-08
| 4H410-15
| 4H430-15
|
Effective Cross Section Area
| 14mm 2 (CV=0.78)
| 25mm 2 (CV=1.40)
| 50mm 2 (CV=2.79)
| 30mm 2 (CV=1.68)
|
Port size
| In=Out=Exhaust=G1/8"
| In=Out=Exhaust=G1/4"
| In=Out=Exhaust=G1/2"
|
Model
| 4H210-08
| 4H230-08
| 4H310-10
| 4H330-10
|
Effective Cross Section Area
| 16mm 2 (CV=0.89)
| 12mm 2 (CV=0.67)
| 30mm 2 (CV=1.68)
| 18mm 2 (CV=1.00)
|
Port size
| In=Out=G1/4" Exhaust=G1/8"
| In=Out=G3/8" Exhaust=G1/4"
|
Working medium
| Air(to be filtered by 40μ filter element)
|
Motion Pattern
| Direct Drive Type
|
Working Pressure
| 0~0.8MPa
|
Temperature
| 0~60 o C
|
