1. Direct acting type and normally closed mode, flexible in direction change.
2.No need to add oil for lubrication
3. Several valves can be installed integrately to save installation place
4. Several standard voltage grades are optional.
Model |
4V220-06 |
Position and Way No. |
Three-position Five-way |
Effective Sectional Area |
12 mm² |
Working Medium |
40 Micron Filtered Air |
Joint Pipe Bore |
Air Inlet=Air Outlet=G1/4" Exhaust=G1/8" |
Motion Pattern |
Inner Guide Type |
Working-pressure |
0.15~0.8Mpa |
Max.Pressure Resistance |
1.2Mpa |
Operating Temperature |
-5~50°C |
Voltage Range |
-10%~+10% |
Protect Class |
IP65 |
Power Consumpton |
AC:4.5VA DC:3W |
Insulation |
F Class |
Wiring Form |
Lead Wire or Connector type |
Highest Action Frequency |
5Cycle/sec |
Shortest Excitation Time |
0.05Second |
