4V400 Series Pneumatic Solenoid Valve
| Price: |
US $ 10.20/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
5/Piece |
| Pay Type: |
L/C,T/T,Western Union |
Regis's all-new directional valves are available in two-way, three-way configurations in port sizes from M5 to 1/2". Select either a direct-acting poppet or solenoid-controlled pilot operated balanced spool design. Spool valves are body ported but can be bolted to a parallel circuit manifold.
These electronic valves offer high flow in a small package, and are constructed of aluminum, stainless steel and thermoplastic materials. The four-way valves are also available in 3 position versions with either pressure center, closed center or exhaust center spool options.
Materials: Aluminum, Stainless Steel, Thermoplastic
Maximum Pressure: Vacuum to 150 psig (direct acting only); 20 to 125 psig (spool valves)
Response Time: Less than 20 ms
Mounting: Manifold standard.
Manual Override: Locking or non-locking
Electrical Connection: DIN terminal with LED Indicator or Wire Lead
Temperature Range: 0 to 65°C (32° to 150°F)
Seals: NBR
4V Series Solenoid Valve
4V series solenoid valves are suitable for operating double or single acting cylinders in pneumatic control system. They have 5 ports and 2 or 3 positions. And 4 type's valve bodies are provided. They are 4V100, 4V210, 4V310 and 4V410 etc. The ports size can be from M5 to 1/2".
The solenoid operated valves can be mounted in line.
The pilot valve is supplied with manual override and connector as standard.
4V400 Series Pneumatic Solenoid Valve
| SPECIFICATION | |
| Model | 4V410-15 | 4V420-15 | 4V430C-15 | 4V430E-15 | 4V430P-15 |
| Fluid | Air(to be filtered by 40um filter element) | |
| Acting | Internally piloted | |
| Port Size | PT1/2 |
| Orifice size | 50.0MM² (Cv=2.79) | 30.0MM² (Cv=1.68) |
| Valve Type | 5/2 way | 5/3 way |
| Operating Pressure | 0.15~0.8mpa(21-114psi) |
| Proof Pressure | 1.5MPA(215psi) |
| Temperature | "-20~70 |
| Material Of Body | Aluminum alloy |
| Lubrication | Not required |
| Max frequency | 3 cycle/sec |
| Weight | 590G | 720G | 770G |
| Prod Model: |
4V410, 4V420, 4V430 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Valve Type: |
Airtac Type |
| Type: |
Pilot Operated |
| Connection Form: |
Thread |
| Valve Structure: |
Pilot Piston Structure |
| Power Supply: |
AC Solenoid Valve |
| Application: |
Water Industrial Usage |
