Allowable Voltage Range: ± 10%
Insulation & Protection Class: Class B or Equivalent
Excitation Time: 0.05Sec
Power Consumption: AC: Start: 5.6VA, Keep on: 5.4VA; DC: 4W
Surge Voltage Suppressor: AC: Varistor, DC: Diode
Indictor Light: Neon Light, LED
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CN, high precision
3. Valve body was machining by CNC, clean and beautifull
4. Spacial processing of inner hole, small friction resistanceand low starting pressure
5. High-precision pilot accessories, excitation time of only0.05 seconds
6. Imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. With a manual device for installation and testing
10. Copper coil has avariety of voltage available for selection
We can customize according to customers requirement. We are looking forward to your inquiry and we will give you best service.
Model |
Valve Type |
Pipe Size |
Norminal Diameter (mm) |
Applicable Medium |
Pressure
Range |
Operating Method |
Max. Action Frequency |
Lubrication |
Applicable Temperature |
4V110-06 |
2 Positions/5 Ports |
G1/8 |
6 |
Air |
0.15~0.8MPa |
Internally Piloted |
5 Cycles/Sec |
Needless |
-5~50 degree |
4V120-06 |
G1/8 |
6 |
4V210-08 |
G1/4 |
8 |
4V220-08 |
G1/4 |
8 |
4V310-10 |
G3/8 |
10 |
4V320-10 |
G3/8 |
10 |
4V410-15 |
G1/2 |
15 |
4V420-15 |
G1/2 |
15 |
4V210F-06 |
G1/4 |
8 |
4V310F-08 |
G1/4 |
8 |
4V320F-10 |
G3/8 |
10 |
4V330F-10 |
G3/8 |
10 |
Ningbo Bojat Mechanical Technology Co., Ltd. is in the top list of the domestic market. It has professional employees in R&D, manufacture, sales and relative service of the products such as solenoid valves and pneumatic cylinders. Its headquarters locates in Xikou town of Ningbo city, one of the national AAAAA spots which has the profound historical civilization.
Bojat develops from an Auto parts company, which had provided the parts and accessories for Zhengzhou Yutong, Xiamen Golden Dragon, Suzhou Jinlong and other well known auto manufacturers. The company spent several billion yuan to set up Ningbo Bojat Mechanical Technology Co., Ltd. in 2003. It covers an area over 10000 square meters and has 100 employees. We have the most advanced international numerical controlling lathe and working center, which gives a new standard for the pneumatic industry.
Bojat has passed the quality certification of ISO9001: 2000 and keeps improving in the material choosing. Its core accessories such as seal and electromagnetic loop are both imported from abroad with the best quality. First-class talents, advanced equipment, strict quality control system, all provide a solid foundation for the production of high quality pneumatic products. We have received many awards from the national pneumatic association and have been put in the list of the best supplier for many large industrial enterprises.
