Construction is as follows
Full port or conventional port.
Outside screw and yoke(OS&Y)
Two piece self-aligning packing gland
Bolted bonnet & spiral wound gasket seal bonnet
Bolted bonnet with spiral-would gasket seal bonnet
Bonnet or threaded and pressure seal bonnet
Integral backseat
Socket weld ends to ASME B 16.11
Screwed ends(NPT) to ANSI/ASME B 1.20.1
NO. |
Part name |
A105/F6a |
A105/F6aHFS |
LF2/304 |
F11/6aHF |
F304(L)/F304(L) |
F316(L)/F316(L) |
F51/F51 |
1 |
Body |
A105 |
A105 |
LF2 |
F11 |
F304(L) |
F316(L) |
F51 |
2 |
Seat |
410 |
410 |
304 |
410HF |
304(L) |
316(L) |
F51 |
3 |
Wedge |
F6a |
F6a |
F304 |
F6aHF |
F304(L) |
F316(L) |
F51 |
4 |
Stem |
410 |
410 |
304 |
410 |
F304(L) |
F316(L) |
F51 |
5 |
Gasket |
304+Flexible graphite |
6 |
Bonnet |
A105 |
A105 |
LF2 |
F11 |
F304(L) |
F316(L) |
F51 |
7 |
Bolt |
B7 |
B7 |
L7 |
B16 |
B8(M) |
B8(M) |
B8M |
8 |
Pin |
410 |
410 |
410 |
410 |
304 |
304 |
304 |
9 |
Gland |
410 |
410 |
304 |
410 |
304 |
316 |
F51 |
10 |
Gland eyebolt |
B7 |
B7 |
L7 |
B16 |
B8(M) |
B8(M) |
B8(M) |
11 |
Gland flange |
A105 |
A105 |
LF2 |
F11 |
F304 |
F304 |
F304 |
12 |
Hex nut |
2H |
2H |
2H |
2H |
8(M) |
8(M) |
8M |
13 |
Locking nut |
410 |
410 |
410 |
410 |
410 |
410 |
410 |
14 |
Stem nut |
35 |
35 |
35 |
35 |
35 |
35 |
35 |
15 |
Nameplate |
AL |
AL |
AL |
AL |
AL |
AL |
AL |
16 |
Handwheel |
A197 |
A197 |
A197 |
A197 |
A197 |
A197 |
A197 |
17 |
Lubricating gasket |
410 |
410 |
410 |
410 |
410 |
410 |
410 |
18 |
Packing |
Graphite |
Graphite |
Graphite |
Graphite |
Graphite |
Graphite |
Graphite |
Kcm valve co, Ltd. Established in 1983, has 29years history. Kcm is a modernized manufacturing enterprise, which integrates research, develop, manufacture and marketing of industrial valves. Kcm is the abbreviation for the golden key to construct the motherland. It got API, MSS, ISO, EN, BS, JIS, DIN, NF cetifications. Throughout the years kcm has lived up to its kcm meaning as a key to construct the motherland by manufacturing and supplying numerous industrial valves to pipelines in fields of petrochemical, oil refinery, chemical, oil production, electric power station, chemical fertilizer, metallurgical, nuclear power, national defense, pharmaceutical industries. Kcm has become a new and high technological enterprise of zhejiang province, executing unit of the state torch plan projects and a member of sinopec resource equipment market. Kcm major products are gate valve, globe valve, check valve, ball valve, butterfly valve and needle valve with the materials of carbon steel, alloy steel, stainless steel, ultra-low carbon stainless steel and monel etc.
