Marine Bronze Angle Valves JIS F7302 5K.
Our products have 5 years history,
Sold to Western Europe, the USA, Japan, etc.
Marine Bronze Angle Valves JIS F7302
DN L H fLANGE DIMENSIONS HAND WHEEL
D C T N D DO S
15 55 120 80 60 9 4 12 80 8
20 60 130 85 65 10 4 12 100 10
25 65 145 95 75 10 4 12 125 10
32 80 150 115 90 12 4 15 125 10
40 85 165 120 95 12 4 15 140 12
50 100 200 130 105 14 4 15 140 12
65 115 220 155 130 14 4 15 160 14
Capability;
Nominal Pressure 5kgf/cm2(0.49Mpa)
Seal Pressure 7.7kgf/cm2(0.761Mpa)
Intensity Pressure 10.5kgf/cm2(1.046Mpa)
Medium Max Pressure kgf/cm2(Mpa)
Oil & Flow water 5kgf/cm2(0.49Mpa)
Lenitic water<=120 7KG/CM2(0.69Mpa)
Materials of Body/Trim:
Part name Material
Name Mark
Body, Bonnet Tin-bronze ZQSn10-21
Disc, Seat Albronze QAL9-21
Packing PTFE SFT-2
Qingdao V-goal Marine Valve Manufacturing Co., Ltd. has been in the business of producing and manufacturing marine valves for 10 years. We settle in the Marine Fittings Industry Park of Qingdao city of China which is very near to the Qingdao port. With very fantastic location, we have the most convenient transportation all from land, sea and air.
We now have a powerful technical force, wide experiences of design, precision processing machineries, complete testing devices, strict operation system. Better than other companies, we have our own casting foundry and physical and chemical testing devices for materials. With years of manufacturing experience in the field, we can control the quality from the beginning. Now we are supplying semi-finished castings and finished products to several international famous valve companies such as KS, HSN, WKV and OTV. At present, our finished products mainly contain JIS standard of gate valve, globe valve, butterfly valve, check valve, fire valve, storm valve, air pipe head and each kind of spare parts. We have professional technicians and experienced sales team to create the complete processes of casting, manufacturing, testing, assembling, sales and after-sale services. In 2010, we passed the ISO 9001: 2008 and also gained certifications of several classification societies.
Qingdao V-goal Marine Valve Manufacturing Co., Ltd. Pursues excellence and zero defect products, insists the policy of "professional born of concentrated", keeping moving forward and increasing upward. The company will try all the best to stand at the top position of the industry. Create the industry's brand and supply the most trustworthy products.
