Easy installation, maintenance-free, super long life;
Reliable operation, self-adjusting stem seals, cylinder can be 360° Rotated free;
Anti-corrosive, high flow rate, low fluid resistance, no water-hammer;
Optical position indication, low control air consumption.
Control Type: Single acting (NO/NC); Double acting
Size: DN15 ~ DN100
Connection: Flanged(ISO/DIN/JIS is also available)
Actuator Size: 50mm, 63mm, 90mm, 125mm
Body Material: CF8M (AISI 316) or CF8 (AISI304)
Actuator: CF8 (AISI304)
Seat: Teflon (PTFE)
Applicable Fluid: Water, alcohol, oil, fuel, steam, neutral gas or liquid, organic solvent, acid and lye
Fluid Pressure: Max. 1.6MPa (16 bar, 232Psi)
Fluid Temperature: -10 - +180centigrade
Max. Viscosity: 600 mm2/s
Control Fluid: Neutral gas, air
Control Pressure: 0.3 - 0.8MPa
Ambient Temperature: -10- +80centigrade
Options: Solenoid valve, smart positioner, limit switch, stroke limitation, manual override
Founded in 2001, we are specialized in pneumatic valve and stainless steel valve for middle & low-pressure industrial fluid control system. Our products mainly include pneumatic angle seat valve, shuttle valve, pneumatic butterfly valve, ball valve, check valve and strainer, which has been widely exported to US, Europe and worldwide.
As a fully integrated company offering R&D and manufacturing services, all of our products are made under ISO 9001: 2000-certified processes. Our main factory covers 16, 000 square meters, employs over 100 skilled workers and holds 26 advanced CNC lathes. We have also built a strict QC team equipped with CMM from Switzerland and gauges from Japan and the US. This way, we can ensure precise fits and consistent quality on all of your orders.
We also provide OEM services for machining, die casting and investment casting. In fact, we have our own foundry specialized in die and investment casting respectively so that we can provide you with the complex products you require. with over five years of experience, buyers from throughout the world have to come to trust in our products. In fact, the ITT Corporation, US has worked with us for three years.
