API 600 Cast Iron Solid Wedge Gate Valve
Price: |
US $ 49-99/Piece |
Trade Terms: |
FOB,CIF,EXW |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,Paypal |
Solid Wedge Gate Valves
Diameter: DN50-2000 (2inch - 80inch)
Material: Cast Steel, Stainless Steel, Cast Iron
Pressure: 10bar, 16bar
Connection: Wafer, Flange, Lugged
Operated Type: Manual, Pneumatic, Electric, Bevel Gear
Part Name | MATERIAL |
Body | A216 WCB | A352 LCB | A217 WC1 | A217 WC6 | A217 WC9 | A217 C5 | A217 C12 | A315 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
Seat Ring | A105 | A350 LF2 | A182 F304 | A182 F304 | A182 F304 | A182 F304 | A182 F304 | A182 F304 | A182 F316 | A182 F304L | A182 F316L |
Wedge | A216 WCB | A352 LCB | A217 WC1 | A217 WC6 | A217 WC9 | A217 C5 | A217 C12 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
Stem | A182 F6 | A182 F304 | A182 F6 | A182 F6 | A182 F304 | A182 F6 | A182 F6 | A182 F304 | A182 F316 | A182 F304L | A182 F316L |
Bonnet Bolt | A193 B7 | A320 L7 | A193.B7 | A193.B16 | A193.B16 | A193.B16 | A193.B16 | A193.B7 | A193.B7 | A193.B7 | A193.B7 |
Bonnet Nut | A194 2H | A1944 | A194.2H | A193.2H | A194.2H | A194.2H | A194.2H | A194 2H | A194.2H | A194.2H | A194.2H |
Gasket | Stainless steel and graphite spiral wound |
Bonnet | A216 WCB | A352 LCB | A217 WC1 | A217 WC6 | A217 WC9 | A217 C5 | A217 C12 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
Backseat Bushing | A182. F6 | A182. F304 | A182.F6 | A182.F6 | A182.F304 | A182.F6 | A182.F6 | A182.F304 | A182.F316 | A182.F304L | A182.F316L |
Stem Packing | Graphite |
Lantern | A182 F6 | A182 F6 | A182.F6 | A182 F6 | F182 F304 | F182 F6 | A182 F6 | A182 F304 | A182 F316 | A182 F304L | A182 F316L |
Pin | Carbon steel |
Gland | A182 F6 | A182 F6 | A182 F6 | A182 F6 | A182 F6 | A182 F6 | A182 F6 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
Gland Flange | A105 | A350 LF2 | A105 | A105 | A105 | A105 | A105 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
Gland Eyebolt | A307 B | A307 L7 | A193 B7 | A193 B7 | A193 B7 | A193 B7 | A193 B7 | A193 B8 | A193 B8 | A193 B8 | A193 B8 |
Gland Nut | A194 2H | A1944 | A194 2H | A194 2H | A194 2H | A194 2H | A194 2H | A1948 | A1948 | A1948 | A1948 |
Stem Nut | C63000 or A439 D2 |
Retaining Nut | Carbon Steel |
Hand wheel | Ductilelion or Steel |
H.W. Lock Nut | Carbon Steel |
York | A216 WCB |
Nipple | Carbon steel |
Prod Model: |
FYV |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
2''-80'' |
Class: |
150lb-1500lb |
O-Ring Sealing: |
PTFE,NBR,Rptfe |
Ends Con: |
RF,Rtj,Sw,Bw |
Connection Form: |
Thread |
Material: |
Carbon Steel |
Seal Surface: |
Wedge Gate Valve |
Thread Position Of Valve Rod: |
Outside Gate Valve |
Application: |
Household Usage |
Fangyuan Valve Group Co. Ltd, seated at Wuxing Industrial Zone, Oubei, Yongjia County, so called as "Pump & Valve Village of China", close to the national scenic spot Nanxijiang River to the east and facing the downtown of Wenzhou City to the south, and established in 1998 with the former as Zhejiang Fangyuan Valve Manufacturing Co. Ltd, has got a great achievement via hard work and continual going forth ahead and become a magnate of plate gate valve from an unknown small enterprise and leads the future of this industry. Fangyuan Valve Group Co. Ltd was derived from Zhejiang Fangyuan Valve Manufacturing Co. Ltd in 2005 and holds 5 stock subsidiaries, three production bases in Wenzhou, Shanghai and Lishui and a cast base in Lishui, a total registered capital up to 4, 000, 000 USD, a total land area 110000m2, over 600 staff members, 60 of which are technicians, a digital process center and more than 350 sets of various middle and large equipments and an annual output up to 12000 tons.
This Group comes as a key enterprise among the said"Pump & Valve Village of China"and a well known enterprise in the national valve industry and specializes in the production of plate gate valve, gas valve, electric station valve etc., with the development, design and invention patent know-how up to the advanced technical level of the world and the leading level of the nation and some of the products used to replace the imported ones. This Group has been accredited to ISO9001, API6A/6D, CE, AZ etc., won the first prize of scientific advance of Zhejiang Province and elected as a member of the first-grade supply network of China Petroleum, a member of China Petrochemical Resource Market, a member of No. 1 Energy Network, a member for supply of the national electric power system, an appointed production enterprise by Chemical Equipment General Corp., a Wenzhou high-tech enterprise, a start enterprise of Yongjia County, one of the 30 powerful enterprises among the said village and a banking credit AAA grade enterprise in the successive recent years. It holds a powerful strength in the technical, management and market etc. Respects and a notable superiority in the severe market competition.
The products, approved by the nation and province early or late, have been elected as quality products of Zhejiang Province and well-known ones of Wenzhou. This Group follows the guide policy of"takeing people as the base, managing the company with laws, prospecting the enterprise with quality, continuing innovations"and makes the products well sold to all over the country and USA, Canada, the Middle East, Europe etc. World markets, greatly favored by the users therein. Therefore a solid basis has been made for the further open-up of the world market, for the making of Fangyuan brand, for the national industrial progression and for the great target to create a valve magnate of China and step forward to the 50 powerful valve companies of the world.
Slab gate valve: Slab gate and expanding gate, double sealed upstream and downstream design, double block and bleed open and closed design. Size: DN50~DN1400, pressure: PN16~PN420, handwheel, gear, electric, pneumatic.
Fully welded ball valve.
Forged steel valve. Material: A105, LF2, F11, F22, F5, F304, F316, F321 etc.
