Specifications
Design description
1 Full port design
2 Rising stem and non-rising handwheel
3 os&y,outside screw and yoke
4 Bolted bonnet
Design Features
Full port design
OS&Y, outside and screw
Bolted bonnet, back seal structure
Flexible wedge, fully guided
Choice of solid or split wedge
Renewable or welded seat
Extended stem design for low temperature
Flanged or butt-welding ends
Technical Specification
Size:2"-48" or DN50-DN1200
Pressure: Class150-2500LB or PN16-PN250 or 10K-40K
Material:WCB, WCC, LCB, LCC, WC6, WC9, C5, C12, CF8, CF8M, CF3, CF3M, CF8C, CN7M,etc.
Design & Manufacture Std.: API600, ASME B16.34, API6D, BS5351,JIS B2073
Face to Face Std.: ASMEB16.10 (JIS B2002),API 6D, DIN3202, ASME B16.25
End Connection Std.: ASME B16.5,ASME B16.47, JISB2212-JISB2214,
DIN2543-2550,ASME B16.34
Test Standard: ISO5208, API598 (JIS B2003), API 6D, BS 6755
Operated way: Handwheel, Gear, Pneumatic, Electric Actuator
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
