Basic Info.
Model NO.:D343H/F/X-6/10/16/25C
Connection Form:Flange
Work Pressure:Mid-Pressure (2.5mpa< Pn <6.4mpa)
Structure:Three-Eccentric Sealing
Seal Form:Force Sealed
Working Temperature:Medium Temperature (120°C
Application:Water Industrial Usage
Material of Seal Surface:Metal Hard Sealed
Size:Dn100-1600
Package:Standard Export Plywood Cases
Export Markets:Global
Specifications
1. Valve body\disc\yoke\retaining ring: WCB
2. STEM: SS 2Cr13
3. Seal ring: Stainless steel
3. Best price plus fine quality
Package: Usually packeg with plywood, we can make the packing ACCORDING TO YOUR REQURIEMENT, and if the packing cost is different with plywood case, the price will adjust together, more or less.
Standard and Specification:
Manufacture Standard | JB/T8527 |
Structure Length | GB/T12221 |
Match Tube Flange | JB/T74~90, HGJ67, GB/T9112~9131 |
Quality Guarantee | ISO9001 |
Pressure-temperature Grade | GB-T9131, HGJ67, JB/T74 |
Inspection Standard | GB/T13927 |
Nominal Diameter ( DN ) | 40~2400mm |
Nominal Pressure ( PN ) | 0.25~4.0MPa |
Test Pressure ( Ps ) | Seal | 1.1×PN |
strength | 1.5×PN |
Working Pressure | 1.0×PN |
Understanding our customers, we care about the future of our business. Up to today, with reasonable price and good quality, all our products sell well in the international marketing. We want to ensure that you get our good service, only high quality and speedy delivery. We sincerely want to supply you with high quality products and perfect service based on our efficient management and professional work teams. Because professional, so trust!
