API Handwheel Pressure Seal Butt Welded Gate Valve (Z60Y)

API Handwheel Pressure Seal Butt Welded Gate Valve (Z60Y)
Price: US $ 10-100/Piece
Trade Terms: FOB,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
API Handwheel Pressure Seal Forged Gate Valve (Z60Y)


Basic information
Size RangeNPS 2"~48"   DN50~2000mm
Class500LB~2500LB
MaterialWCB,WC6,LCB,WC9,CF8,CF8M,CF3 and CF3M
ConnectionBW
FeatureRising Stem,Flexible wedge,Pressure seat Bonnet
OS&Y Outside screw and yoke,threaded or welded seat ring.
Temperature-30ºC~425ºC
ActuatorElectric operated
ApplicationOil and gas pipeline
Drainage system
Chemical Plant



Manufacture Standard
Design standardAPI600,API6D,BS1414,ASME/ANSI B 16.34
Face to faceASME/ANSI B 16.10
BW End ConnectionAS,E/ANSI B 16.25
Inspection and testAPI598


Why choose us?
l   Professional manufacturer with many years' experience in this area.
l   Best price with superior quality.
l   3-5 hours fast reply.
l   OEM service acceptable, customer providing sample for special requirement is accepted.
l   Low MOQ with convenient payment, support Western Union,Paypal.
l   Meet delievery date in time.

Prod Model: Z60Y
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size Range: Nps 1/4"~2" Dn8~50mm
Class: 500lb~2500lb
Material: Carbon Steel
Connection Form: Thread
Seal Surface: Wedge Gate Valve
Thread Position Of Valve Rod: Outside Gate Valve
Application: Industrial Usage
Yongjia Jiali Valve Manufacture Co., Ltd. is a professional valve manufacturer located in China famous Pump$Valve Town-Oubei. The main of our products are Gate Valves, Globe Valves, Check Valves, Ball valves, Plug valves, Butterfly valves, Strainer and other special valves applied broadly in petroleum, chemical, metallurgical and power station industries.

Established in 2004, Jiali Valve has grown up into a professional manufacturer integrating valve design, production, sale and service. The company covers more than 60series and thousands of specifications which strictly comformed to international advanced standards such as API, ANSI, BS, DIN, NF, JIS, JPI, GB, JB and so on. We can also casting and processing valves according to the client's special requirement.

The Products nominal diameter (NPS), 1/4"-44"(DN8-DN1400);

Pressure class from 150LB to 2500LB (PN0.1MPa-32MPa);

Operating temperature: -196° C~680° C;

Main materials includes WCB, WC6, WC9, C5, C12, LCB, LCC, CF8, CF8M, CF3, CF3M, CF8C, etc.

Jiali Valve has established a perfect quality control in order to ensure excellent quality and service. The company has a sophisticated processing center, testing and inspecting center, chemical composition analysis center, mechanical performance test, nondestructive inspection, liquid pressure test, low leak test as well as various special facilities. Just because of these strict quality control system and advanced technical support, our company are highly recognized and trusted by our customers including Europe, America, Middle East, Southeast Asia. etc

Technology innovation, strict quality control, perfect after-sales service, Jiali valve casts higher quality valves, we are always doing the best. We warmly welcome clients all over the world come to visit us to create a brilliant future.
