| Price: | US $ 9.9-1499/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
Main features and applications:
1. It has compact structure, reasonable design, good rigidity, smooth channel, small flow resistance coefficient.
2. The sealing surface is made of stainless steel or hard alloy with long service life.
3. It applies the flexible graphite packing which is reliable in sealing and easy to operate.
4. The driving modes are divided into manual, electrical, pneumatic and gear.
5. The Structure: flexible wedge type single gate, rigid wedge type single gate and double gate type.
6. Its widely used in the petrochemical, thermal power plants and other oil, the opening and closing device of water and steam pipe to cut off or connect the medium of the pipeline.
Advantages:
1. Small fluid resistance
2. The torque for opening and closing is small, so it is easy to open and close.
3. The medium flowing direction is not restricted, and it doesn't disturb flowing and reduce the pressure of pipeline.
4. Short length structure
5. Good sealing performance
6. Simple shape, good casting process.
Executive Standard:
1. Design and manufacture: API 600, ANSI B16.34, BS 1873, E101.
2. Inspection and Test: API 598, E 101
3. Flange: ANSI B 16.50
4. Welding junction: ANSI B 16.25
5. Face to face: ANSI B16.10, E 101
| Prod Model: | Z40Y |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: | Inches |
| Connection Type: | Flange |
| Material: | Carbon Steel |
| Connection Form: | Flange |
| Seal Surface: | Wedge Gate Valve |
| Thread Position Of Valve Rod: | Outside Gate Valve |
| Application: | Water Industrial Usage |
