Home Valve Products Aseptic Diaphragm Valve Stainless Steel Manual Pneumatic Straight Tank Multi-Port
Aseptic Diaphragm Valve Stainless Steel Manual Pneumatic Straight Tank Multi-Port
| Price: |
US $ 1-50/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal,Money Gram,Western Union |
Applicationsaseptic diaphragm valve can be remote controlled by an actuator or manually operated by a handle. It is very applicable to the control of pipe fluid and the switching task. It is widely used in pharmaceutical, dairy, beverage and brewing industries with aseptic working conditions requirements.Operating PrincipleThe tight mating of valve body and diaphragms makes the valve body and valve seats sealed, which ensures absolute isolation of internal pipeline and external environment. Therefore the valve is applicable to the aseptic process.The up and down movement of valve stem causes WJ6 aseptic diaphragm valve to open or close. When valve stem moves upwards, spherical diaphragms naturally bend upwards and separate from valve seat, the valve is open then. When valve stem moves from top to bottom, valve plug makes diaphragms bent and clung to valve seat, the valve is closed then.WJ6 aseptic diaphragm valve can be operated manually, by pneumatic actuator, or by smart controller.
Technical Data
Metal material | Product wetted | 316L(1.4404) |
Non-product wetted | 304(1.4301) |
We can provide EN 10204 3.1B certificate for all metal materials. |
Seal material | Standard | PTFE bellow |
Options | 316L / PTFE bellow |
All seal materials comply with FDA 177.2600. |
Temperature | Continuous working temperature | -20~+135ºC(PTFE) |
Sterilization temperature | 150ºC(max 60min) |
Pressure | Working pressure | 0~5bar |
Control air pressure | 5~8bar |
Surface treatment | Internal surface | Ra≤0.6μm |
External surface | Ra≤1.6μm |
Connection | Connection standards | Welding end: DIN 11866 series 1 |
Welding end: DIN 11866 series 3 |
Connection methods: welding, thread, clamp, flange |
Options | Smart controller | 24V DC |
solenoid valve (1) |
Position sensor | 24V DC |
NPN/PNP position sensor (1 or 2) |
Any question, be free to contact us, we are professional manufacturer for this field for more than 10 years. We will reply you within 24 hours. We are here waiting for your
Sincere cooperation.We have been a professional manufacturer and sales for high precision sanitary valves, pipe fittings, pipe connecting fittings, precise forging, forged valve and OEM forging parts ect. Which use for food, beverage, pharmacy, biology engineering, water treatment cosmetic, petroleum and chemical industry area, etc. Its advantages are with forging, heat treatment and machining.We have many many testing equipemnts and instruments. Which are dimensional measuring machine, spectroscopic analysis equipment, hardness equipment, optical instrument etc.We have the best team of experts in the management and technology. We design and produce our products as BPE, DIN, SMS, 3A, IDF, RJT, ISO and BS etc stanrard strictly. We test each step from raw-material to finished products. They avouch us to control the material quality, and finished products quality.So far quality controls systems ISO9001 and Safety "CE" certification, and SGS had gotten through.
| Prod Model: |
YH-GMF001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Ss Material: |
Forged Stainless Steel 304, 304L, 316, 316L |
| Material: |
Stainless Steel |
| Structure: |
Through Way Diaphragm Valve |
| Function: |
Intelligent Type |
| Standard: |
JIS |
| Actuator: |
Manual or Pneumatic |
| Connection: |
Welded or Clamped |
We have been a professional manufacturer and sales for high precision sanitary valves, pipe fittings, pipe connecting fittings, precise forging, forged valve and OEM forging parts ect. Which use for food, beverage, pharmacy, biology engineering, water treatment cosmetic, petroleum and chemical industry area, etc. Its advantages are with forging, heat treatment and machining.
We have many many testing equipemnts and instruments. Which are dimensional measuring machine, spectroscopic analysis equipment, hardness equipment, optical instrument etc.
We have the best team of experts in the management and technology. We design and produce our products as BPE, DIN, SMS, 3A, IDF, RJT, ISO and BS etc stanrard strictly. We test each step from raw-material to finished products. They avouch us to control the material quality, and finished products quality.
So far quality controls systems ISO9001 and Safety "CE" certification, and SGS had gotten through.
Wenzhou Yeahoo Industrial Co., Ltd with many year's constant effects, we started our own business by experence accumulation and source integration. We have been a professional manufacturer and sales for high precision sanitary valves, pipe fittings, pipe connecting fittings, precise forging, forged valve and OEM forging parts ect. Which use for food, beverage, pharmacy, biology engineering, water treatment cosmetic, petroleum and chemical industry area, etc. YEAHOO enterprise, its advantages are with forging, heat treatment and machining. Has many forging machines of 400Ton, 630 Ton, 1000Ton, free forging and ring forging limit 280.00cm under making new toolings by ourselves. In additional, we have machining centre with more 15 MAZAK CNC machines and many milling machines. YEAHOO's Lab has many many testing equipemnts and instruments. Which are dimensional measuring machine, spectroscopic analysis equipment, hardness equipment, optical instrument etc.
We have the best team of experts in the management and technology. We design and produce our products as BPE, DIN, SMS, 3A, IDF, RJT, ISO and BS etc stanrard strictly. We test each step from raw-material to finished products. They avouch us to control the material quality, and finished products quality.
YEAHOO continue pursuing superior grade quality and steady development. So far quality controls systems ISO9001 and Safety "CE" certification had gotten through. Products of "YEAHOO" Brand is sold to Europe, South America, North America, south east Asian country and Area. Creating a YEAHOO culture based on "innovation, service and cooperation". With outstanding management, advanced technical equipment, we provide high lever products and perfect services to our clients.
Building a trusted brand of "YEAHOO" and becoming a leader for valves and fittings. Let's cooperation together.
