DMC sereis Dust collector are designed and manufactured by us combing with Fuller's, USA design and our rich experience, it take high pressure big flow pulse valves to get much better filter efficiency then other dust unites, it has several advantages, smaller, lighter, simple construction, easy installation, easy maintanance, external type filtration. Our DMC dust collector are now widely used in dust collecting in construction materials industry, metalurgy, mine, chemical, coal industries, high filtration efficiency and collector micro particles.
Specification:
Model |
PPC32-3 |
PPC32-4 |
32-5 |
32-6 |
64-4 |
64-5 |
64-6 |
64-7 |
64-8 |
Air volume (m3 /h) |
6900 |
8930 |
11160 |
13390 |
17800 |
22300 |
26700 |
31200 |
35700 |
Total filter area (m2) |
93 |
124 |
155 |
186 |
248 |
310 |
372 |
434 |
496 |
Chamber(pcs) |
3 |
4 |
5 |
6 |
4 |
5 |
6 |
7 |
8 |
Quantity of filter bag(pcs) |
32 |
64 |
Total quantity of filter bag(pcs) |
96 |
128 |
160 |
192 |
256 |
320 |
384 |
448 |
512 |
Pulse valve |
Quantity |
3 |
4 |
5 |
6 |
4 |
5 |
6 |
7 |
8 |
Specification |
1 |
2 |
Specification of filter bag |
130(D.)*2450 |
Filter material |
Based on flue gas properties |
Filtration speed |
0.8~2.0(Adjustable) |
Negative pressure |
less than 6000 |
Resistance |
1470~1770 |
Inlet dust concentration |
less than 200 |
less than 1000 |
Blowing pressure |
0.5~0.7 |
Compressed air consumption |
0.27 |
0.37 |
0.46 |
0.55 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
Air-locking unit |
Adjustable |
Screw conveyor |
No |
Adjustable |
Area of heat preservation |
26.5 |
34 |
41 |
48.5 |
70 |
94 |
118 |
142 |
176
|
Hangzhou Grace Envirotech is a joint venture in China combined with Grace Filter Manufacturing (U. K) Limited. We are the largest manufacturer of Filter Needle Felts, filter bags, Dust Collectors, and dust collector parts; Meanwhile, we are designing and producing dust collecting system for cement plant, power plant, as well as iron and steel plant. Our company is the largest enterprise in the dust collecting industry in China,
Our factory is located in Industrial Area in Hangzhou, four big needle felt production lines. We have formed big scale production by our advanced equipment and mature technology. We design dust collecting system, produce filter bags for customers and users, and provide site technology consultant service, design, production, as well as after-sale service.
Nomex filter bag, PPS filter bag and P84 filter bags are now our star products in the world, highly popular in cement plant and power generation plant in all of the world.
Meanwhile, we are expertise in Dust Collector desgin, manufacturing and installation.
With many years of experience, Grace Filter is recognized around the world as the leading filtration dust filter bag and dust collection machine producer. Our experience make it possible for us to produce a complete range of filtration felt which meet customer specific filtration requirement. We have made great progress in supplying filter media in the cement industry, waste incinerator industry, power generation industry which make us on of the leading manufacturer and suppliers in the world.
Our professional technical team will provide pre-sales, manufacturing, delivery and after-sales service for dust collector units, dust collector system, baghouse bag filter, our professional installation workers will keep your dust collection system work perfectly and simple
