Designs
Design in accordance with API 602
Flanged RF / RTJ, socket weld, threaded or combined
Bolted bonnet or welded bonnet options
Renewable or integral seats
Low fugitive emissions control
NACE Service either MR-0175 or MR-0103
Test in accordance with API-598
Materials
Forged carbon steel A105
Low alloy steel ASTM A182 gr. F1, F11 and F22
Medium alloy steels ASTM A182 gr. F5, F9, and F91
Stainless steel ASTM A 182 gr. F304/304L, F316/316L, F321, F347, F348
Duplex Stainless Steel ASTM A 182 gr. F44 (6Mo), F51, F53 or F55 (superduplex)
High nickel molybdenum alloys (alloy 20, inconel, monel)
Dimensional Range
NPS: 1/4'' - 2"
Pressure rating: ANSI 150 - 2500#
Other Information
For any valve inquiry, please specify the following infomation:
1. Valve type and design pressure/temperature
2. ANSI pressure class, Operating temperature, operating / differential pressure
3. Bore Size, pipe schedule ID / OD
4. Body and trim material
5. Medium, Flow rate Min. /Max.
6. Type of end connection
7. Actuation (manual, gear, actuator and type)
The features of globe valve
Bolted Bonnet; Outside Screw and Yoke; Rising stems; Metallic seating surfaces.
Body and Bonnet Connection
The body and bonnet of Class150~Class900 globe valves are usually bolted bonnet design. And the Class1500~Class2500 globe valves are usually of pressurized seal design.
Gasket of Cover Flange
Stainless steel + flexible graphite wounded gasket is used for Class 150 and Class 300 globe valve. Stainless steel + flexible graphite wounded gasket is used for Class, and ring joint gasket is also optional for Class 600. Ring joint gasket is used for Class 900 globe valve. Pressurized seal design is used for Class 1500~Class 2500 globe valve.
Actuation
Hand wheel, impact hand wheel and gear box is usually used for globle valve actuation. Chain wheel and electric acduator can be also used for globle valve actuation if being reguested by the customers.
Belleville spring loaded packing impacting system
If being requested by the customer, the Belleville spring loaded packing impacting can be adopted for enhancing the durability and reliability of the packing seal.
Back seating design
All our globe valves have the back seating design. In most cases, the carbon steek globe valve is fitted with a renewable back seat. For stainless steek globe valve, the back seat is machined directly in the bonnet or is machined after welding. When the globe valve is at fully open position, the sealing of the back seat can be very reliable. However, as per the requirement of API, it is not advisable to add or change packing by the mean of back seating when the valve is pressure containing.
Seat
For carbon steek globe valve, the seat is usually forged steel. The sealing surface of the seat is spray welded with hard alloy specified by the customer. Renewable threaded seat is used for NPS<10 globe valve, and welded on seat can be also optional if being requested by the customer. Welded on seat is used for NPS>12 carbon steel globe valves. For stainless steel globe valve, intergral seat is usually adopted, or to weld hard alloy directly intergrally. Threaded or welded on seat is also optional for stainless steel globe valve if being requested by the customer.
Stem design
The stem is of integral forged design. The minimum diameter of the stem shall per the standard requirement.
Stem nut
Usually, the stem nut is made of ASTM A439 D2. It is also can be made of copper ally if being requested by the customer. For large sized globe valve, rolling bearing is fitted at the two sides of stem nut in order to minimize the open and close torque of the globe valve.
Special globe valve
Besides the common globe valves, we also makes cryogenic globe valve, bellow sealed globe valve, Jacketed globe valve, etc.
|
NO. |
Part Name |
CS to ASTM |
AS to ASTM |
SS to ASTM |
|
Type A105 |
Type F22 |
Type F304(L) |
Type F316(L) |
|
1 |
Body |
A105 |
A182 F22 |
A182 F304(L) |
A182 F316(L) |
|
2 |
Disc |
A276 420 |
A276 304 |
A276 304(L) |
A276 316(L) |
|
3 |
Stem |
A182 F6 |
A182 F304 |
A182 F304(L) |
A182 F316(L) |
|
4 |
Gasket |
Corrugated SS + graphite |
SS + PTFE |
|
5 |
Bonnet |
A105 |
A276 304 |
A276 304(L) |
A276 316(L) |
|
6 |
Bonnet Bolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
7 |
Pin |
A276 420 |
A276 304 |
|
8 |
Gland |
A276 410 |
A182 F304(L) |
A182 F316(L) |
|
9 |
Gland Eyebolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
10 |
Gland Flange |
A216 WCB |
A351 CF8 |
|
11 |
Gland Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
12 |
Yoke Nut |
A276 410 |
|
13 |
H.W. Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
14 |
Nameplate |
SS |
|
15 |
Hand wheel |
A197 |
|
16 |
Stem Packing |
Flexible Graphite |
PTFE |
|
Suitable Medium |
W.O.G. etc |
W.O.G. etc |
HNO3CH3OOH etc |
|
Suitable Temperature |
-29°C~425°C |
-29°C~550°C |
-29°C~180°C |
