Product discription:
1) Size: 1/2"-24"
2) Pressure: 150-300lbs
3) Applicable temperature range: -200-350¡ãC
4) Material: WCB/SS304/SS316
5) Applicable medium: nitric, acetic acid, water, oil, gas and some corrosive liquids
Parts Materials:
Part Name | CF8 SERIES | CF3 SERIES | CF8M SERIES | CF3M SERIES | WCB SERIES |
BODY | CF8 | CF3 | CF8M | CF3M | WCB A216 |
DISC | F304 | F304L | F316 | F316L | 2CR13 |
Stem | F304 | F304L | F316 | F316L | 2Cr13 |
PACKING | PRFE | PTFE | PTFE | PTFE | GRAPHITE |
GASKET | PTEF+304 | PTEF+304L | PTEF+316 | PTEF +316L | GRAPHITE 304 |
GLAND | CF8 | CF3 | CF8M | CF3M | WCB |
BOLT | A193-B8 | A193-B8 | A193-B8M | A193-B8M | 35CrMoA |
NUT | A194-8M | A194-8M | A194-8M | A194-8M | 45 |
STANDARDS:
PRODUCT | DESIGN & MANUFACTURE | PRESSURE AND TEMP RATING | DIMENSIONS | FLANGE END | BUTT-WELDING END | TEST PRESSURE |
ANSI GATE VALVE | ANSI B 16.34 | ANSI B 16.34 | ANSI B 16.10 | ANSI B 16.5 | ANSI B 16.25 | API 598 |
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
