Design Features
Straight pattern body design
OS&Y, outside screw and yoke
Tapered, globe, or plug disc
Renewable or welded seat
Bolted bonnet, back seal structure
Impact handwheel for 10" and above
Extended stem design for low temperature
ISO top flange for Bare stem globe valve
Technical Specification
Size: 2" -24" or DN 50-DN600
Pressure: Class150LB-2500LB or PN16-PN160 or 10k-40k
Material: WCB,LCB,WC6,WC9,C12,C5,CF8,CF8M,CF3,CF3M etc.
Design & Manufacture Std.: API600,ASME B16.34,BS1873
Face to Face Std.:ASMEB16.10, JISB2002,DIN3202,BS2080
End Connection Std.: ASME B1.20.1,ASME B16.11,ASME B16.5, JISB2212-JISB2214, DIN2543-2551
Test Standard: ISO5208, API598, JISB2003, BS 6755
Operated way: Hand wheel, Gear, Pneumatic, Electric Actuator.
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
