Specification
1.Size:DN50-DN600(2"-24")
2.Pressure:PN10 PN16 PN25
3.Working temperature: t≤80ºC
Standards Compliance
1.Design standard:API600,API6D;DIN3352;EN10434
2.Face to Face:ASME B16.10;DIN3202;EN558
3.Flange standard:ASME B16.5, ASME B16.47;DIN2543-2545;EN1092
4.Inspection and test:API598,API600;DIN3230;EN12266;
5.Pressure and temperature:ASMEB16.34;DIN2401
Materials of main parts
Body:cast steel,gray cast iron,ductile iron
Disc:body+NBR/EPDM
Seat ring:NBR
Stem:stainless steel
Pad:NBR,EPDM
The main technical data
1.Shell test pressure(MPa):1.5PN
2.Seal test pressure(MPa):1.1PN
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
