Available in DIN, ANSI, JIS and BS Standards
Features
Available in both OS&Y, Bolted bonnet and NRS (Non-rising Stem) constructions
Standard Material available in:
Body/Bonnet: Cast Iron and Ductile Iron
Stem: Stainless Steel
Seat: Cast Iron, Ductile Iron, Brass, Stainless Steel
Disc: Ductile iron covered with NBR/EPDM
Handwheel: Cast Iron or Ductile iron
Size ranges available from 2" through 12"
Pressure Rating in ANSI 125 & ANSI 150
Operation: Handwheel, Cap Top, Gear Operator, Penumatic & Hydraulic
Technical Data
Design & manufacture: ANSI B16.10, MSS SP-71
Face to face dimension: ANSI B16.10, MSS SP-71
Flanged dimension: ANSI B16.1/16.5
Inspect and test: ISO 5208/API598
Since 1989, Sino Valve has dedicated itself to manufacture a wide range of industrial valves for the services of Oil, Gas, Refinery, Chemical, Marine, Power Station. 90% of our valves are OEM for European and United State valve brand, so top quality can be assured with competitive price.
