MATERIAL LIST
NO. | Part | Materials | Optional Material |
1. | Body | Cast iron | Ductile Iron |
2. | Seat | Buna-N or EPDM | Neoprene,Hypalon,Viton,Food Grade EPDM,PTFE |
3. | Disc | Ductile Iron | 316SS,304SS |
4. | Shaft | SS410 | 304,316Stainless Steel,Monel |
5. | Key | Carbon Steel | None |
6. | O-Ring | Bune-N | None |
7. | Bushing | Lubricated Bronze | Fiberglass Backed PTFE |
PRODUCT DESCRITION
1.Suitable Temperature:BUNA-N(NBR)≤80°C EPDM ≤120°C VITON ≤150°C
2.Suitable Media:FreshWater,Sewage,SeaWater,Air,Vapour,Food,Medicine,Oils,Acids,Alkalis,Salts,Etc.
**Manufacturing connecting flange in the with:
DIN2501 PN6/10/16
ANSL 125/150
BS10 Table D&E
BS4504 PN6/PN10/PN16
JIS B2220 10K/16K
**Test standard: API598 DIN3230
**Face to Face:GB/T12221-1989
DIN3202-1999 K1
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
