Application
1 Face to face is according to JISB2002
2 Flange srilled is according to JISB2212
Test
Workingpressure 10K
TestpressureShell 21.1kgf/cm2
Seat 15.0kgf/cm2
Components
Body cast iron (FC20)
Bonnet cast iron (FC20)
Stem stainless steel (SS410)
Disc cast iron (FC20)
Seatring cast bronze / stainless steel(B62/SS304)
Gland ductile iron (FCD45)
Packing not sabestos
Handwheel cast iron (FC20)
