Specification:
Size: 2"- 20"
Design standard: API 609, BS EN 593, MSS SP-67.
Face-to-Face dimension: API 609, ISO 5752, BS EN 558, BS 5155, MS SP-67.
Flange Drilling: ANSI B 16.1, BS EN 1092, DIN 2501 PN 10/16, BS 10 Table E,
JIS B2212/2213 5K, 10K, 16K.
Test: API 598.
Pressure & Temperature ratings:
Working Pressure | PN10 / PN16 |
Testing Pressure | Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. |
Working Temperature | -10°C to 80°C (NBR) -10°C to 120°C (EPDM) |
Suitable Media | Water, Oil and gas. |
Materials:
Parts | Materials |
Body | Cast iron, ductile iron, carbon steel, stainless steel |
Disc | Nickel ductile iron / Al bronze / Stainless steel |
Seat | EPDM / NBR / VITON / PTFE |
Stem | Stainless steel / Carbon steel |
Bushing | PTFE |
"O" ring | PTFE |
Pin | Stainless steel |
Key | Stainless steel |
