Cast Steel Soft Sealing Double Eccentric Butterfly Valve Class150/300 (SFDXWF-2ET)
| Price: |
US $ 50/Piece |
| Trade Terms: |
CFR |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Cast steel butterfly valve pn16/25
Double eccentric type.
Seat seal in EPDM
Available NBR or viton seal
Spring back seat for retaining.
Connection: Wafer type, lug type
Size: Dn50-dn300
Working pressure and temperature
Carbon steel: NBR seat: -12 c ~82 c
EPDM seat: -45 c ~135 c
Csm(hypalon) seat: -18 c ~135 c
Viton seat: -12 c 135 c
PTFE seat: -18 c~180 c
Stainless steel: NBR seat: -12 c~82 c
EPDM seat: -45c ~135 c
Csm( hypalon) seat: -18c ~135 c
Viton seat: -12 c~135 c
PTFE seat: -18 c ~180 c
General design specifications:
Item Germany standard
Manufacture: DIN3202
Face to face: API 609
End flange: DIN 2543/2544
Inspection and test: DIN 3320
Test pressure to DIN3320:
Pn shell (water): 16 2.4mpa
25 3.75mpa
Seat (water): 1.76mpa
2.75mpa
Seat (air): 0.6mpa
0.6mpa
| Prod Model: |
SFDXWF-2ET |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Connection Form: |
Wafer |
| Working Temperature: |
Medium Temperature (',120??C
|
| Work Pressure: |
High Pressure (',10.0mpa< Pn <80.0mpa) |
| Seal Form: |
Auto Sealed |
| Material Of Seal Surface: |
Soft Sealed |
| Structure: |
Double-Eccentric Sealing |
Shanghai Ciphy Industry Co., Ltd. Are a specializing supplying various valves, pipe, fittings, flanges and plate & sheet company in China; All sold product must be tested and inspected in test locale by our company colleague; We are very luck that to day our product is no wrong for our every customers.
Our product as follows:
Standard: ANSI Standard, BS Standard, DIN Standard, JIS Standard etc.
Material: Cast Iron(A126 FC20, GG20), Ductile iron(FCD45, GGG40), Malleable iron, Cast Steel(A216-WCB, A352-LCB, A217-WC1/WC5/WC6/WC9), Forged Steel(A105, F5, F11, F22, LF2), Stainless Steel(A351 CF8/CF8M/CF3/CF3M, A182 F304/F316/F304L/F316L), Alloy steel(ALLOY20), Titanium alloy etc.
Size: From 1/2 inches to 48 inches from 15mm~1200mm.
Valve: Gate valve, Globe valve, Check valve, Ball valve, Butterfly valve, Plug valve, Chose valve, Needle valve, Knife gate valve, resilient gate valve, bellow globe valve etc.
Flange: Welded Neck, Slip-on, Socked Weld, Lap Joint, Blind, Threaded? etc.
Fitting: 45D, 90D & 180D Elbow, Reduced & Equal Tee, Concentric & Eccentric Reducer, Cap etc.
Connect: Flanged ends, Butt-welding ends, Socket welding ends, Threaded ends etc.
Pressure grade: ANSI CLASS 125, CLASS 150, CLASS 300, CLASS 600, CLASS 800, CLASS 900, CLASS 1500, CLASS 2500, DIN PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160, JIS 5K, 10K, 20K etc.
Moreover, we are also engage in processing trade; We can manufacture the products exactly as per the custormer's specific requirements such as nominated trademark and marking, the customer's own technical drawings, etc.
If you find anything interesting here, please do not hesitate to contact us. What you will get is quality products with competitive prices. If you require something not included in this catalogue, please also let us know. With the help of several cooperate factories.
Look forward to having a chance to serve your esteemed company.
