Quick Details
Standard or Nonstandard: Standard
Structure: Ball
Pressure: Low Pressure
Power: Electromotion
Material: Ceramic
Temperature of Media: Low Temperature
Media: Water
Place of Origin: Zhejiang, China (Mainland)
Model Number: HL-5
Brand Name: HELI
Packaging & Delivery
Packaging Details: Foam package inside, Carton outside
Delivery Detail: Within 7 days after receiving payment
Item
Power
Performance |
HL-05 |
|
DC12V |
DC24V |
DC220V |
AC24V |
AC110V |
AC220V |
AC380V |
|
|
Motor power |
20W |
10W |
|
Rated current |
3.8A |
2A |
0.21A |
2.2A |
0.48A |
0.24A |
0.15A |
|
|
Output torque |
30Nm/50Nm |
15Nm/30Nm/50Nm |
|
Action time |
6S/10S |
10S/20S/30S |
|
Circuit control |
B,S,R,H,A,K,D,T |
|
Rotary angle |
0-90° |
|
Weight |
2.2kg |
|
Voltage-withstangdingvalue |
500VAC/1minute(12V,24v) |
1500VAC/1minute(110V,220V,380V) |
|
Insulated resistance |
100MΩ/300VDC(12V,24V) |
100MΩ/500VDC(110V,220V,380 |
|
Protection class |
IP-67 |
|
Surrounding temperature |
-25ºC-60ºC(The other temperatures can be customized)
|
|
Installation angle |
Any angle |
|
Case material |
Aluminium die-casting components
|
|
Optional function |
Overload protection function .Heater
|
