| Price: | US $ 11-15/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 300/Piece |
| Pay Type: | L/C,T/T |
| NO. | Type No. | Produce Name |
suitable Medium |
PN (Mpa) |
DN (mm) |
Outlet thread(mm) |
Jiont Thread to cylinder (mm) |
Temp./Pressure of safety device |
| 1 | CGA870A | Cylinder valve for oxygen (O2) | O2 | 15 | 1.5 | Ø7 clip2-Ø4.7 fixed mpin | 3/4-16-UNF | steelcylinder21-23.2 Aluminum cylinder22.9-25.5 73deg±3deg |
| 2 | CGA870-1 | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø4.7 fixed mpin | 1/2-NPT | 21±1.5 |
| 3 | CGA870-2 | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø4.7 fixed mpin | 3/4-14-NGT | / |
| 4 | CGA870-2A | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø4.7 fixed mpin | GB8335 PZ27.8 | / |
| 5 | CGA870-2B | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø6 fixed mpin | GB8335 PZ27.8 | / |
| 6 | CGA870-2C | Cylinder valve for N2O | N2O | 15 | 2.5 | Ø7 clip2-Ø6 fixed mpin | GB8335 PZ27.8 | / |
| 7 | CGA870-3 | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø4.7 fixed mpin | 1/2-NGT | / |
| 8 | CGA870-3B | Cylinder valve for oxygen (O2) | O2 | 15 | 2.5 | Ø7 clip2-Ø4.7 fixed mpin | 1/2-NGT | / |
| 9 | CGA870-4 | Cylinder valve for oxygen (O2) | O2 | 15 | 1.5 | Ø7 clip2-Ø4.7 fixed mpin | BS3411-1/14 | / |
| 10 | CGA870-4A3 | Cylinder valve for oxygen (O2) | O2 | 15 | 3 | Ø7 clip2-Ø4.8 fixed mpin | 3/4-16-UNF | 73deg ±3deg |
| 11 | CGA870-5 | Cylinder valve for oxygen (O2) | O2 | 15 | 3 | Ø7 clip2-Ø6 fixed mpin | BS3411-1/14 | / |
| 12 | CGA870-6 | Cylinder valve for oxygen (O2) | O2 | 15 | 3 | Ø7 clip2-Ø4.7 fixed mpin | 3/4-14-NGT | / |
| 13 | GA870B | Cylinder valve for oxygen (O2) | O2 | 15 | 1.5 | Ø7 clip2-Ø4.7 fixed mpin | 3/4-16-UNF | / |
| 14 | CGA910 | Cylinder valve for N20 | N20 | 15 | 1.5 | Ø7 clip2-Ø4.8 fixed mpin | 3/4-14-NGT | / |
| 15 | CGA670 | Cylinder valve for Mixed gas | Mixed gas(Cl2,etc) | 2 | 7 | Male thread CGA670 | 3/4-14-NGT |
/ |
| Prod Model: | CGA870-2C |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: | Manual |
| Media: | Gas |
| Structure: | Control |
| Pressure: | Medium Pressure |
| Temperature Of Media: | Normal Temperature |
| Outlet Threead: | R7mm Clip1-Diameter 6 Mm Fixed Pin |
| Inlet Thread: | GB8338 Pz 27.8 |
| Loading Port: | Shanghai Port |
| Delivery: | Within 16 Days |
