China manufacture diaphragm direct lifting water solenoid valve gas solenoid valve
Characteristic: 1 Direct lifting diaphragm construction
2 Open from zero bar for low pressure system use
3 High frequency of flying lead coil
Medium: Air, City Gas, Water, Oil, Petroleum, etc
Temperature: NBR Seal: -10 º C to 80 º C
EPDM Seal: -10 º CTO 120 º C
VITON Seal: -10 º C to 150 º C
Pressure: 2W21: 0 ~ 1.0MPa
Port Size: 3/8'', 1/2'', 3/4'', 1'', 11/4'', 11/2'', 2''
Port Thread: G, BSP, NPT, Flange
Orifice(mm): 12, 15, 20, 25, 32, 40, 50
Voltage: DC- 12V, 24V
AC-24V, 120V, 240V/60Hz; 110V, 220V/50Hz
Tolerance: +/-10%
Coins: S51B: 30VA(AC), 24W(DC), IP65, 100%ED
SD01B: 28VA(AC), 36W(DC), IP65, 100%ED
Material: Body- Brass
Seal- NBR, EPDM, PTFE or VITON
Armature Tube - Stainless Steel 304
Plunger - Stainless Steel 430F
Stop - Stainless Steel 430F
Springs - SS304
Shading Rings - Stainless Steel304
Product advantage: 1 open from zero bar for low pressure system use
2 CE, TUV, RoHS, DVE approved
3 Integrated armature tube
Our service
1)Our advantage: Yuyao Yongchuang Solenoid Valve Co. Ltd. Is a technical company specialized in designing and manufacturing solenoid valves, cylinders, flow meters, and heating air-conditioning control products. Our products have been widely applied in the automation of the fluid control.
2)Terms of payment: TT, LC, Western union.
3)Shipment: Average 20-25days after receiving deposit.
4)Delivery: Ningbo /Shanghai, by sea or air.
5) Packing: 31*21*25cm carton
6)Gurantee: One year since delivery.
7)Inspection: 100% testing for all the valves
If you are interested in our product, please do not hesitate to contact us.
Emily Yan
Fax: 86-574-62505192
Tel: 86-574-62507206 13738891676
|
2W21 Normally open |
|
|
|
|
|
|
|
|
|
Valve Body |
Port Size |
Orifice |
Cv |
Min Pressure |
Max Pressure |
Seal Material |
Body Material |
Coil |
|
2W21 |
3/8 '' |
12 |
4.5 |
0.0Mpa |
1.0Mpa |
NBR,EPDM, or VITON |
|
S51B |
|
2W21 |
1/2 '' |
15 |
4.5 |
0.0Mpa |
1.0Mpa |
|
S51B |
|
2W21 |
3/4 '' |
20 |
9.3 |
0.0Mpa |
1.0Mpa |
Brass or |
S51B |
|
2W21 |
1 '' |
25 |
12 |
0.0Mpa |
1.0Mpa |
Stainless Steel |
S51B |
|
2W21 |
1 1/4 '' |
32 |
24 |
0.0Mpa |
1.0Mpa |
|
SD01B |
|
2W21 |
1 1/2 '' |
40 |
29 |
0.0Mpa |
1.0Mpa |
|
SD01B |
|
2W21 |
2 '' |
50 |
48 |
0.0Mpa |
1.0Mpa |
|
SD01B |
