4HSeries 5way pneumatic single coil directional solenoid valves factory
Features
Integral slot piston structure
Process valve hole with special high precision finishing process
Beautiful appearance
Good reverser
Reliable performance
Seal wear can automatic compensate
300 Series Solenoid Valve, Pneumatic Control Valve
1.3/2 5/2 way valve
2.Long lifecycle
3.Coils made by hands
Specifications
Good quality and favolable price.
V series solenoid valve and pilot valve is the common controlling element, which has the full kinds of port size, from 1/8 to 1.And It also has different specification, flow rate and position.It has many connecting ways with the execution element.
Odel | HK4H210-08 |
| Position and way NO. | 5/2 way 5/3 way ,3/2 way |
| Effective area | 16mm2(CV=0.89) |
| Port size | Air inlet=Air outlet=1/4'' Exhaust=G1/8″ |
| Fluid | 40 micron filtered air |
| Operation | Inside pilot type |
| Operating pressure | I0.15~0.8MPa |
| Max.Proof pressure | 1.2MPa |
| Temperature | 5~50 C |
| Allowable boltage | ±10% of rated voltage |
| Power consumption | AC:2.5VA DC:2.5W |
| Coil insulation &protection grade | Class F.IP65 |
| Electriacl entry | Lead wire or connector |
| Higest action frequency | 5 cycle/second |
| Shortest excitation time | 0.05 second |
FAQ
Q:How much is our minimum order quantity?
A:Our minimun quantity is 1 Piece.
Q:Could you offer the free samples?
A:Yeah,we could offer the free samples for the massive products.
Q:What's your business scope?
A:Our business scope is air cylinder,air source treatment ,air solenoid valve ,motorize valve ,
Pneumatic valve ,quick fitting,etc.
Q:What's your delivery date?
A:It depends on the number of orders.Delivery date is 7-30 days.If you need emergency products,
We can speed up the production of the first arrangement.
Q:What is the price of the product?
A:Our prices are based on the size and type of material, if you can give me the information,
Then we can give you an estimated price is for reference only.We can do any size and any color.
Q:What types of products you can make ?
A:We can make many kinds of stainless steel materials processing.Valve/ solenoid valve /electric
Valve /pneumatic valve and air cylinder products and so on.
Q:How many years do you warrant?
A:18 months warranty.
Q:How many years have you done valves,cylinders?
A:More than 13 years.
Q:Do you company have specialized technical personnel?
A:Do you company have specialized technical personnel,they can design the product which the most meet your requirements.
Q:Can the product be made with our logo and brand?
A:Yes,of course,we can make .We are OEM supplier for years and professional to make.But you need give us the authorization if it is possible.
Our company specializes in the production of solenoid valve and pneumatic valve on pipeline fluid. COVNA, original brand, runs its business around the world and its quality awards ratification through competing with European countries, the United State, Japan and other major industrial countries in the international market.
By far, export production ranks first in the country with its sale throughout the country in the field of two position two way solenoid valve. Since the general manager has entered into the industry of valve, pipeline fluid automation and labor saving, he has hold the Three First Business Philosophies of quality first, service first, and credit first all the time. It makes the quality and output of our products advance at an equal pace with them from Europe, the United State and Japan in the international market. With reasonable price, even the medical device industry in France, Spain and other countries install our products, COVNA solenoid valves.
