Cuniform gate valve
Usage:This product is extensively used in Petro-chem industry,pharmacy and power industry etc.And it can be fixed onto pipes whose flowing agents include steam,water and oil etc.
Z45T/W-10/10Q Z45T/W-169/16Q Main parts and materials
| Parts name | Material |
| Valve body.Bonnet | Grey iron.Ductile iron |
| Disc | Grey iron.Ductile iron |
| Stem | Carbon Steel.Brass.Stainless steel |
| Yoke nut | Brass.Ductile iron |
| Hand wheel | Grey iron.Ductile iron |
Z15T-16 Main parts and materials
| Parts name | Material |
| Valve body.Bonnet | Grey iron.Ductile iron |
| Disc | Grey iron.Ductile iron |
| Stem | Carbon Steel.Brass.Stainless steel |
| Hand wheel | Grey iron.Ductile iron |
Function and specification
| Type | Nominal pressure (MPa) | Testing pressure | Suitable temperature( °C ) | Suitable medium | |
| Strength(Water)(MPa) | Enclose(Water)(MPa) | ||||
| Z45T-10 | 1.0 | 1.5 | 1.1 | ≤100 | Vapour Water |
| Z45W-10 | Oil | ||||
| Z15T-16 | 1.6 | 2.4 | 1.8 | ≤200 | Vapour Water |
Outline and connecting measurement
| Prod Model: | 16c |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: | Carbon Steel |
| Thread Position Of Valve Rod: | Inside Gate Valve |
| Application: | Water Industrial Usage |
| Connection Form: | Inside Thread |
| Actuator: | Spurgear |
| Seal Surface: | 2Cr13 |
