Danfoss Solenoid Valve Evr3 (032F1206)

Price:	US $ 40/Piece
Trade Terms:	FOB
Min Order:	20/Piece
Pay Type:	L/C,T/T

Contact Supplier

Shenzhen Sino-Australia Refrigeration Equipment Co., Ltd.

Showroom Product Company Profile

Complete range of solenoid valves for refrigeration, freezing and air conditioning plant

Supplied both normally closed (NC) and normally open (NO) with de-energized coil

Wide choice of coils for a. C. And d. C.
Suitable for all fluorinated refrigerants

Designed for media temperatures up to105 C

MOPD up to 25 bar with 12 W coil

Flare connections up to 5/8 in.

Solder connections up to 2 1/8 in.

Extended ends for soldering make installation easy It is not necessary to dismantle the valve when soldering in.

EVR are also available with flange connections

Model	Coil Type	Connection Size		Product Code (body without coil)
		Connection Size		Flared	ODF
		in.	mm	In./mm	in.	mm	With manual operation	Without manual operation
EVR2	a.c.	1/4	6	032F8056	032F1201	032F1202
EVR3	A.c./d.c.	1/4	6	032F8107	032F1206	032F1207
EVR3		3/8	10	032F8116	032F1204	032F1208
EVR6		3/8	10	032F8072	032F1212	032F1213
EVR6		1/2	12	032F8079	032F1209	032F1236
EVR10		1/2	12	032F8095	032F1217	032F1218
EVR10		5/8	16	032F8098	032F1214	032F1214
EVR15		5/8	16	032F8101	032F1228	032F1228
		5/8	16	032F8100			032F1227
		7/8	22		032F1225	032F1225
EVR20	a.c.	7/8	22		032F1240	032F1240
		7/8	22				032F1254
		1-1/8	28		032F1244	032F1245
	d.c.	7/8	22		032F1264	032F1264
	d.c.	7/8	22				032F1274
EVR22	a.c.	1-3/8	35		032F3267	032F3267
EVR25	A.c./d.c.	1-1/8					032F2200	032F2201
			28				032F2205	032F2206
		1-3/8	35				032F2207	032F2208
EVR32		1-3/8	35				042H1105	042H1106
		1-5/8					042H1103	042H1104
			42				042H1107	042H1108
EVR40		1-5/8					042H1109	042H1110
			42				042H1113	042H1114
		2-1/8	54				042H1111	042H1112

EVR3 032F1204

EVR3 032F8107

EVR3 032F8116

EVR3S 032F1206

EVR3S 032F1207

EVR6 032F1209

EVR6S 032F1212

EVR6S 032F1236

EVR6S 032F8072

EVR6S 032F8079

EVR10 032F8095

EVR10 032F8098

EVR10S 032F1217

EVR10S 032F1214

EVR15 032F8101

EVR15S 032F1225

EVR15S 032F1227

EVR15S 032F1228

EVR20 032F1240

EVR20 032F1244

EVR20 032F1245

EVR20 032F1274

EVR22 032F3267

EVR25 032F2200

EVR25 032F2201

EVR25 032F2205

EVR25 032F2208

EVR32 042H1104

EVR32 042H1105

EVR32 042H1106

EVR40 042H1109

EVR40 042H1110

EVR40 042H1111

EVR40 042H1112

Prod Model:	EVR3 ( 032F1206)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Internal:	External
Type:	Direct Acting
Connection Form:	Thread
Valve Structure:	Pilot Piston Structure
Power Supply:	AC Solenoid Valve
Application:	Household Usage
