Quick Details
Standard or Nonstandard: |
Standard |
Structure: |
Gate |
Pressure: |
Low Pressure |
Power: |
Manual |
Material: |
ductile iron with EPDM/NBR |
Temperature of Media: |
Medium Temperature |
Media: |
water |
Port Size: |
40-600mm |
Place of Origin: |
Hebei, China (Mainland) |
Model Number: |
YDP9 |
Brand Name: |
LIQIAN |
Product information
Main Parts and Materials |
| Parts name | Material |
| Body,Bonnet | Ductile iron |
| Disc | Ductile iron with EPDM/NBR |
| Stem | Stainless Steel |
Standards |
| Design and Manufacture | Face to Face | Flange End | Inspection |
| DIN3352 F4/F5 | DIN3202/ISO5752 | DIN2501/GB-17241 | DIN3230/JB-T9092 |
Test Pressure |
| Nominal Pressure(Mpa) | Strengh Testing(Mpa) | Seal Test(Mpa) |
| 1.0 | 1.5 | 1.1 |
| 1.6 | 2.4 | 1.8 |
Dimension
DN(mm):40/50/65/80/100/125/150/200/250/300/350/400/450/500/600mm
Our Services
Competitive Price: We are the manufacturing company which not only has our own manufacturing workshop, but the casting company as well. So we can provide the straight factory price and service to our customer.
OEM Accepted: We can make the products with the client's demand standard, and also have many experience on OEM.
Good Quality: We have strict quality control system and amounts of testing equipments for different kind of valve, such as size, pressure, working environment etc.
100% QC inspection Before Shipment.
Quick Delivery: We have the large stock for some hot products.
Xingtai City Liqian Import & Export Co., Ltd is committed to providing high-quality industrial valves to the international customers. Our factory has a 60-year history on researching, developing, manufacturing and marketing of industrial valve products that are widely used in Oil & Gas, Water Treatment, Power Generation, Petroleum Refinery, Chemical & Petrochemical, and Paper & Pulp industries. It is located in Tianjin-Bohai Economic Center, with strong geographical advantages and development spaces, now becoming the largest valve manufacturer in China. It has passed the authentication of ISO9001: 2008 quality management system, ISO 14001: 2004 environmental management system, and OHSAS 18001: 2007 Occupational Health & Safety System, also with CE, API, KS and GOST certification.
Our exported products include USA ANSI, API, AWWA standard valves, Germany DIN standard valves, England BS standard valves, Japan JIS standard valves, Russia GOST standard valves, France NF standard valves, etc. And the types covering gate valve, globe valve, ball valve, butterfly valve, check valve, diaphragm valve, reducing valve, plug valve, traps valve, etc. With stable quality and long using life, our valves are very popular in USA, Europe, Russia and Middle East markets.
To choose Liqian Valve means to choose safety. We would like to enjoy a win-win cooperation with the customers all over the world!
