Body:Cast iron/Ductile iron
Nut/bolting:Carbon Steel
Ball:Stainless Steel 304
Seat:PTFE
Stem:SS304
Lever:Ductile Iron(GGG40)
Operation:handle lever/gear box/actuators
Size:DN25~DN250
Pressure:PN10/16
Standard:
Working temperature: -20 °C ~ +120 °C
Face To Face :DIN3202 DN15-DN100 DIN3202 (F4)
DN125-DN250 DIN3202 (F5)
End Flange Dimensions:EN 1092-2 etc.
Testing:DIN3230,API598
Medium:Water,oil,gas etc.
NO. | part name | material |
1 | body | gg25,ggg40 |
2 | bonnet | gg25,ggg40 |
3 | ball | ss304 |
4 | seat | ptfe |
5 | gasket | ptfe |
6 | stem | ss304 |
7 | lever | ggg40 |
8 | bolting | carbon steel |
9 | nut | carbon steel |
