Quick Details
Standard or Nonstandard: Standard
Structure: Ball
Pressure: Medium Pressure
Power: Electromotion
Material: Casting
Temperature of Media: Normal Temperature
Media: Water
Port Size: 6NM, 8NM
Place of Origin: Zhejiang, China (Mainland)
Model Number: HL-ZX
Brand Name: HELI
Certificate: CE, CQC, ISO9001: 2000
Packaging & Delivery
Packaging Details: Exporting case
Delivery Detail: Within 30 days upon receipt of T/T
Specifications
Compact design, high quality but competitive price
Model
Performance | HL-ZX |
| Power | AC85-260V | AC24V | DC24V | DC12 |
| Output torque | 6Nm/8Nm |
| Time | 7S/9S |
| Rated current | 0.2A | 0.15A | 0.15A | 0.3A |
| Rotary angle | 0~90° |
| Insulated resistance | Any angle |
| Installation angle | Any angle |
| Case Material | Aluminium die-casting components |
| Position-Iimiting | When power-operated: completely switching on or off;
When manually operated: mechanical block. |
| Protection class | IP67 |
| Surrounding temperature | -25°C~60°C |
