Rated voltage: AC100V/110V/115V/120V +_10% 50/60Hz 1-ph
AC200V/220V/230V/240V +_10% 50/60Hz 1-ph
Control: 0~90(Full close~full open)
Torque: 87in-1b (9.807N/m)
Operating time: 4/3.3sec(50/60HZ)
Output signal: O/C voltage-output(STD)
O/C No-voltage contact output(Option)
4~20mA/DC(Option)
Potentio-resistance output(Option)
Protection: Motor thermal protectoe (120)
O/C Mechanical stopper(STD)
Full close/full open limiter(Option) at either one side
Manual operation: Crank handle (STD), Declutch hand wheel(Option)
Output shaft shape: Male square(STD), Female(Option)
Coating color: Electrostatic coating/Grey (Munsell N-6)
WEIGHT: 2.3kg.
