Maitechnical parameter
DN 50 65 80 100 125 150 200 250 300 350 400
A 145 145 145 145 182 182 182 182 182 182 182
B2 196 196 196 196 248 248 248 248 248 248 248
L 108 112 114 127 140 140 152 165 178 190 216
N 4--18 4--18 8--18 8--18 8--18 8--22 8--22 12--22 12--22 16--22 16--26
D 125 145 160 180 210 240 240 350 400 460 515
Voltage AC380V. AC220V. AC110V. DC24V
On-Off time 15s, 30s, 45s, 60s
Protection grade 1p67
Valve body material stainless steel, carbon steel
Sealing material Hard-alloy, NBR
Media oil, water, steam, acid, alkali, solid pellet
Nominal Pressure 1.6Mpa, 1.0Mpa
Electric ball valve
Ruian hongli roboticized meter factory is a specialized manufactory electric actuators. Electric valve and automatic control system.
