Exe Solenoid Valve 5/2 Way Foot Pedal Air Valve 4f210-08LG
| Price: |
US $ 2.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
Product Description 5/2 way thread connection Foot Pedal Air Valves 4F series foot valve, it is 5/2way, controlled by foot step on it. With different type: Lock type, protecting cover type, lock & protecting cover type. We can also develop & produce it as your special needs. 1. Model: 4F210-08F210-08L, 4F210-08G, 4F210-08LG, FV420, FV3202. Working medium: air3. Direct drive type4. Lock type & protecting cover type5. ISO9001 & CE approved| Model | 4F210-08 | 4F210-08L | 4F210-08G | 4F210-08LG |
| Fluid | Air(to be filtered by 40μm filter element) |
| Operating | Acting type conterolled by foot |
| Port size | 1/4 |
| Valve type | 5 port 2 positiong |
| Pressure range | 0-0.8MPa(0-114Psi) |
| Proof pressure | 1.5MPa |
| Temperature | -20-70 |
| Material of body | Aluminum alloy |
| Lubrication | Not required |
| Prod Model: |
Pedal Air Valve 4F210-08LG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001:2008 |
| Thread Standard: |
NPT, BSPT, Bsp |
| Export Markets: |
Global |
| Voltage: |
AC110V 220V DC12V 24V |
| Fluid: |
Air, Water, Gas, Oil |
| Pressure Range: |
0~0.8MPa |
| Port Size: |
1/4" |
| Way: |
5 Way 2 Position |
| Proof Pressure: |
1.5MPa |
| Lead Time: |
15-20 Days |
| Connection Form: |
Thread |
| Type: |
Direct Acting |
| Valve Structure: |
Direct-Acting Piston Structure |
| Application: |
Household Usage |
| Material: |
Aluminum Alloy |
| Power Supply: |
AC/DC Solenoid Valve |
Ningbo Excellence Automatic Industrial Co., Ltd is a leading pneumatic products manufacturer in China. And our products covers solenoid valve, air source treatment unit, control element and executive element etc, which are widely used in industries such as machinery, textile, food, enviromental protection. Our company posesses all the production capability and capacity to produce from raw material up to the finished product under requirement of ISO9001: 2008 and CE.
This production capability, coupled with R&D incorporating new technologies and know-how, enables us to serve long lasting, reliable products which can expand to a wide range of diversity.
Our goal is supplying the best qualtiy and service through advanced technology to customers.
Welcome to Ningbo Excellence Automatic Industrial Co., Ltd!
