Thermostatic expanion valve(Core can be exchanged)
This type of thermostatic expanion valve is spcially designded for the refrigeration. It is applicable to cold cabinet & refrigeration displaying cabinet of supermarket, ice-cream machine, cold storeroom, refrigerator car and so on. TI( S)( E) can control the refrigeration system stably and accurately in large scope of temperature by chosing nominal capacity neatly.
Characteristic:
1 The valve body are made in a forge and the membrane are made of solid stainless steel;
2There are altogether eight kinds of stainless steel core for choice and the capacity can be adjusted neatly.
3 Attached filter net which can be cleaned;
4 Refrigeration: R12, R22, R502, R134A, R407c, R404A, R507;
5 Safety work pressure: 35bar (500Psi);
|
T1 |
S |
E |
-M |
W |
|
Series name |
Tie-in form |
Equation mode |
Refrigeration |
fill |
|
|
S stands for solder |
E stands for external equation |
M: R134a,H: R22 , S: R404A/R507 , N: R407C |
W: liquid |
|
Equation |
Connetion form |
R134A |
R22 |
R404/R507 |
R12 |
|
Internal |
flare |
TI-MC |
TI-HC |
TI-SC |
TI-FC |
|
Internal |
solder |
TIS-MC |
TIS-HC |
TIS-SC |
TIS-FC |
|
External |
flare |
TIE-MC |
TIE-HC |
TIE-SC |
TIE-FC |
|
External |
solder |
TISE-MC |
TISE-HC |
TISE-SC |
TISE-FC |
|
Refrigeation |
Male refrigeration KW |
|
Type |
TIO-00X |
TIO-000 |
TIO-001 |
TIO-002 |
TIO-003 |
TIO-004 |
TIO-005 |
TIO-006 |
|
NO. |
800532 |
800533 |
800534 |
8005352 |
8005362 |
8005372 |
800538 |
800539 |
|
R134a |
0.3 |
0.8 |
1.9 |
3.1 |
5.0 |
8.3 |
10.1 |
11.7 |
|
R22 |
0.5 |
1.3 |
3.2 |
5.3 |
8.5 |
13.9 |
16.9 |
19.5 |
|
R404A |
0.4 |
1.0 |
2.3 |
3.9 |
6.2 |
10.1 |
12.3 |
14.2 |
|
R407C |
0.5 |
1.4 |
3.5 |
5.7 |
9.2 |
15.0 |
18.3 |
21.1 |
|
R507 |
0.4 |
1.0 |
2.3 |
3.9 |
6.2 |
10.1 |
12.3 |
14.2 |
|
R12 |
0.2 |
0.7 |
1.5 |
2.5 |
4.0 |
6.6 |
8.0 |
9.3 |
|
R401A |
0.4 |
0.9 |
2.3 |
3.7 |
5.9 |
9.9 |
12.0 |
13.9 |
|
R401B |
0.4 |
1.0 |
2.3 |
3.8 |
6.1 |
10.2 |
12.4 |
14.4 |
|
R402A |
0.4 |
1.0 |
2.4 |
3.9 |
6.3 |
10.3 |
12.5 |
14.4 |
|
R402B |
0.4 |
1.1 |
2.7 |
4.5 |
7.2 |
11.8 |
14.3 |
16.5 |
|
R403B |
0.4 |
1.0 |
2.5 |
4.2 |
6.7 |
11.0 |
13.4 |
15.5 |
|
R407A |
0.5 |
1.3 |
3.2 |
5.3 |
8.6 |
14.0 |
17.0 |
19.6 |
|
R407B |
0.4 |
1.0 |
2.6 |
4.2 |
6.8 |
11.1 |
13.5 |
15.6 |
|
R408A |
0.4 |
1.2 |
2.9 |
4.7 |
7.6 |
12.4 |
15.1 |
17.5 |
|
R409A |
0.4 |
1.1 |
2.7 |
4.3 |
7.0 |
11.6 |
14.2 |
16.4 |
|
R409B |
0.4 |
1.0 |
2.3 |
3.8 |
6.1 |
10.1 |
12.2 |
14.2 |
|
R413A |
0.3 |
0.8 |
1.9 |
3.1 |
5.0 |
8.3 |
10.1 |
11.7 |
|
R502 |
0.4 |
0.9 |
2.1 |
3.6 |
5.7 |
9.3 |
11.3 |
13.1 |
