Flow Control Valve (FS-M-PS019)

Flow Control Valve (FS-M-PS019)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal,Western Union
We are first class retailer, wholesaler, and exporter for flow control valve FS-M-PS019 in China since 2009. Quick response, fast delivery.
Application:
The flow control valve can be widely used in petrochemical industry, water treatment for environmental protection (Chiller, Heat pump water heater ), welding equipment, laser equipment and some other systems for monitoring. The switch with high performance, it equipped with permanent magnet. Just has one removable part. The Operating principle is easy
Characteristic:
*No wearing and fatiguing parts applied, featuring stable performance and long service time.
*Tap water or oil applied, without using filters.;
*It could be installed horizontally and vertically;
*Full nylon structure, various liquid corrosion resistance.
*Obstruction of the liquid is small, high effciency.
*Max pressure is greater than 2Mpa; .
Operation Explain
Flow switch is mainly used in the system to instruct switch on/off according to flow rate. To set a highest lowest flux in the flow switch, when the flow rate reach the set value, flow switch releases signal or alarm, and the system will work or stop.
Electrical Characteristic:
Electrical Characteristics Units
Material   NYLON
Ring Material   NYLON
Tempe Rating ºC  30~+90
Max Pressure MPa 2
Max Volume   30L
Max Contact Rating W 70
Max Switching Voltage VDC ≤230
Max Switching Current A 1.0
Max contact Resistance mOhm 200
Electrical Life (at Resistance load ) VDC/mA 1.5x10 7  (20/500)
Cable Type   UL1332-AWG22
Cable Length mm 400
Cable Color   Black

Prod Model: FS-M-PS019
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Principle: Eddy Current
