Forged Steel Gate Valve with Flanged Ends (Z41H)

Forged Steel Gate Valve with Flanged Ends (Z41H)
Price: US $ 10-100/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Product Details: Gate Valve is used when the need exist for a device that allows an interruption or cut off the flow of a fluid. It is not recommendable to use Gate Valves for flow modulation as the high velocity of the through may result in erosive damage to the wedge and seats when the valve is partially opened. Under normal operating conditions, the valve should remain either fully open or fully closed. Gate Valve is widely used for the medium of water, steam, air, oil, petroleum and petroleum products, nonaggressive fluids. Applicable Standard Design Standard: API 602, BS 5352 Face to Face: Factory's standard Flange ends: ASME B16.5 Inspection and Test: API 598 Design Features Outside screw & Yoke (OS & Y) Standard or Full Port Extended stem for Cryogenic service Integral flange or welding flange options Bolted Bonnet, Welded Bonnet or pressure seal options Size: 1/2" ~ 2"(DN15 ~ DN50) Rating:   ANSI 150lb ~ 2500lb Body Materials:   A105, LF2, F91, F11, F22, F304, F304L, F316, F316L, F321, F51, etc. Operation: Hand wheel Please contact us for other sizes, pressures and materials.
Prod Model: Z41H
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 1/2" ~ 2"(Dn15 ~ Dn50)
Connection Form: Flange
Material: Stainless Steel
Seal Surface: Wedge Gate Valve
Thread Position Of Valve Rod: Outside Gate Valve
Application: Household Usage
JCIN VALVE is a leading manufacturer and supplier of valves for Oil, Gas, and Power Generation industries.

The main products include Gate Valves, Globe Valves, Check Valves, Butterfly Valves, Dual Plate & Strainers, in forged or cast steel. Our product range starts from 1/2" and extends to 36" valves with pressure ratings ANSI / ASME Class 150 to 2500 Lbs, and DIN PN 16 to PN 100.

The highest quality and variety of used materials (Carbon Steels, Low Temperature Carbon Steel, Alloy Steels, Stainless Steels, and other special alloy steel according to ASTM & ASME) can satisfy all the requirements of the Chemical, Petrochemical and Power Plants, Oil and Gas, Off-Shore & On-Shore, Refining, Ship Building, Water Treatment & Energy Generation.

JCIN VALVE's annual sales include 80% for international market, which mainly exported to South Africa, Italy, Poland, Spain, and South America area, we are strive to become a global brand of industrial valve.

At JCIN VALVE, Our main target is to offer a high quality product and service to ensure the highest degree of satisfaction and fidelity of our customers.

JCIN VALVE---Your honest partner on Industrial valve.
