Specifications:
1.？？？？ BB - Bolted bonnet ？
2.？？？？ OS&Y - outside screw and yoke ？
3.？？？？ Socket weld ends: ASME B 16.11 ？
Threaded ends: ANSI/ASME B 1.20.1
Butt-welded ends: ANSI B16.25
4.？？？？ Stem seal consists of flexible graphite packing
5.？？？？ Forged Steel Globe Valves conform to ASME B16.34 and BS 5352. Each valve is tested in accordance with API 598, and marked per MSS SP 25.
6.？？？？ Main materials: A105, LF2, F5, F22, F304, F316, F347, F321, F51, Monel, 20# Alloy
7.Pressure:800lb-2500lb
Application standards
1.Design and manufactory conform to ASME B 16.34
2.Connection ends conform to:
1 )Scoket welded ends conform to ANSI B 16.11;JB/T1751
2)Screw ends conform to ANSI B 1.20.1;JB/T7306
3)Butt-welded ends conform to ANSI B 16.5;JB/T12224
4)Flange ends conform to ANSI B 16.5;IB79
3.Test and inspection conform to:API598;GB/T13927;JB/T9092
？
？
？
？
？
？
？
|
Body |
A105/F6a |
A105/F6aHFS |
LF2/304 |
F11/F6aHF |
F304(L)/304L |
F316(L)/316L |
|
Disc |
A105 |
A105+HF |
LF2 |
F11+HF |
F304(L) |
F316(L) |
|
Stem |
410 |
410 |
304 |
410 |
304(L) |
316(L) |
|
Bonnet |
410 |
410 |
304 |
410 |
304(L) |
316(L) |
Zhejiang xiongtai valve manufacturing Co., Ltd., eattablished in 1998 and situated in Oubei Yongjia, a China hometown of pump and valve is a plant integrating R&D, production, sales and survi of valves and has abundent strengths and plentiful production experience with a staff of about 200 involving several steel valve and steel valve etc., and has obtained certifications of ISO9001, API6D, TS and so on.
